ILSCO AK-350 Aluminum Split Bolt, Main Range 350-1/0, Tap Range 350-4, Tin Plated, UL, CSA
- MPN: AK-350
- UPC: 783669008364
- PPN: ILC-AK-350
CAD
$223.71
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Aluminum Split Bolt, Main Range 350-1/0, Tap Range 350-4, Tin Plated, UL, CSA
Documentation & Downloads
Specifications
Key Specifications
- Height
- 1.5 in
- Weight
- 0.4562 lbs
Length3.24 in
Width1.69 in
Voltage
- Voltage Rating
- 35 kV
Dimensions
- Drive Size Main
- 1-11/16, 1-1/2
- Height BX (IN)
- 2.25
- Width BX (IN)
- 4.375
Drive Type MainExternal Hex
Weight BX (LB)0.614
Testing Standards
- CSA File Number
- 72632
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL / CULUS Specification
- UL 486A/B Listed
CSA StandardC22.2 No. 188, C22.2 No. 65
UL Control Number670B
UL File NumberE6207
Additional Class Attributes
- Connection
- Mechanical
- Number of Poles
- 1
Number of Conductors1
Material and Finish
- Conductor Material
- Aluminum, Copper
- Material
- Aluminum
Connector FinishTin
Conductor Ranges
- Conductor Range AL Stranded (Primary, run, main, line)
- 350 kcmil - 1/0 Str COMPACT
- Conductor Range CU Stranded (Primary, run, main, line)
- 350 kcmil - 1/0 Str COMPACT
Conductor Range AL Stranded (Secondary, tap, load)350 kcmil - 4 Str
Conductor Range CU Stranded (Secondary, tap, load)350 kcmil - 4 Str
Additional Technical Specifications
- Conductor Type
- Stranded, Solid
General
- Bag Quantity
- 1
- Direct Burial
- No
- NEMA Code
- S-588-4
Carton Quantity DescriptionSTD PACK QTY 1
Dual RatedYes
UPC Code78366900836
Bolt and Screw Sizes
- Number of Wire Binding Screws per Port
- 1
Wire Binding Torque650
Color
- Color
- Silver
Environment and Temperature
- Temperature Rating
- 90°C
