ILSCO AK-500 Aluminum Split Bolt, Main Range 500-400, Tap Range 500-2, Tin Plated, UL, CSA
- MPN: AK-500
- UPC: 783669008371
- PPN: ILC-AK-500
CAD
$251.00
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Aluminum Split Bolt, Main Range 500-400, Tap Range 500-2, Tin Plated, UL, CSA
Documentation & Downloads
Specifications
Key Specifications
- Height
- 1.73 in
- Weight
- 0.675 lbs
Length3.62 in
Width2 in
Voltage
- Voltage Rating
- 35 kV
Dimensions
- Drive Size Main
- 2, 1-3/4
- Height BX (IN)
- 2.25
- Width BX (IN)
- 4.875
Drive Type MainExternal Hex
Weight BX (LB)6.9905
Testing Standards
- CSA File Number
- 72632
- Prop65 Compliance
- This product is in compliance with Prop65. It is not known to contain any chemicals associated with this regulation
- UL / CULUS Specification
- UL 486A/B Listed
CSA StandardC22.2 No. 188, C22.2 No. 65
UL Control Number670B
UL File NumberE6207
Additional Class Attributes
- Connection
- Mechanical
- Number of Poles
- 1
Number of Conductors1
Material and Finish
- Conductor Material
- Copper, Aluminum
- Material
- Aluminum
Connector FinishTin
Conductor Ranges
- Conductor Range AL Stranded (Primary, run, main, line)
- 500 kcmil - 400 kcmil COMPACT
- Conductor Range CU Stranded (Primary, run, main, line)
- 500 kcmil - 400 kcmil COMPACT
Conductor Range AL Stranded (Secondary, tap, load)500 kcmil - 2 Str COMPACT
Conductor Range CU Stranded (Secondary, tap, load)500 kcmil - 2 Str COMPACT
Additional Technical Specifications
- Conductor Type
- Stranded, Solid
General
- Bag Quantity
- 1
- Direct Burial
- No
- NEMA Code
- S-588-4
Carton Quantity DescriptionSTD PACK QTY 1
Dual RatedYes
UPC Code78366900837
Bolt and Screw Sizes
- Number of Wire Binding Screws per Port
- 1
Wire Binding Torque825
Color
- Color
- Silver
Environment and Temperature
- Temperature Rating
- 90°C
