APC SMT2200C Smart-UPS 2200VA Line Interactive 120V 8x NEMA 5-15R + 2x NEMA 5-20R Outputs
- MPN: SMT2200C
- UPC: 731304331049
- PPN: APC-SMT2200C
CAD
$2410.45
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Smart-UPS 2200VA Line Interactive 120V 8x NEMA 5-15R + 2x NEMA 5-20R Outputs
Features
- StruxureWare Data Center Expert compatible — Enables centralized management via StruxureWare Data Center Expert.
- Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services. — Innovative, easy to use remote monitoring feature that provides automatic notifications, firmware updates, and advanced support services.
- Reduces utility costs, generates less heat. — Reduces utility costs, generates less heat.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- Energy meter — Provides actual kilowatt hours of usage for energy conscious users.
- Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning. — Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Intuitive LCD interface — Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding. — Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- Pure sine wave output on battery — Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Sequenced network shutdown and reboot — Customize network shutdown and reboot sequence of connected servers and UPSs.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- SmartSlot — Customize UPS capabilities with management cards.
- Temperature-compensated battery charging — Prolongs battery life by regulating the charge voltage according to battery temperature.
Documentation & Downloads
Specifications
Additional
- Capacity
- 1920 VA
- Voltage
- 120 V AC 1 phase
- Output Voltage
- 120 V AC 1 phase
- Output Waveform
- Sine wave
- Outlets
- 8 NEMA 5-15R, 2 NEMA 5-20R
- Typical Recharge Time
- 3 h
- Battery Charge Power
- 271 W
- Height
- 17.13 in (435 mm)
- Depth
- 21.42 in (544 mm)
- Cable Length
- 6 ft (1.83 m)
- Harmonic Distortion
- Less than 5%
- Surge Energy Rating
- 530 J
- Storage Temperature Range
- 5 to 113 °F (-15 to 45 °C)
- Storage Altitude
- 0 to 50,000 ft
- Noise Level
- 45 dBA
- Compliance
- cULus, ENERGY STAR V2.0 (USA), RoHS Compliant with Exemptions, Prop 65 Compliant
- Country of Origin
- Vietnam
- Mount Position
- Front
Power Rating1980 W
Input Voltage Range75...154 V adjustable
Output Frequency50/60 Hz +/- 3 Hz
Transfer Time6 ms typical, 10 ms max
Battery TypeLead-Acid battery
Battery Life3-5 years
Communication PortSmartConnect Ethernet port, SmartSlot
Width7.72 in (196 mm)
Weight112.24 lb (50.91 kg)
Input Connection TypeNEMA 5-20P
TopologyLine Interactive
Operating Temperature Range32 to 104 °F (0 to 40 °C)
Operating Altitude0 to 10,000 ft
Relative Humidity0 to 95%
Heat Dissipation275 Btu/h
MaterialMercury Free
ColorBlack
