Balluff BCS R08RRE-NOM80C-EP02 Capacitive Sensor, 1-8 mm Range, IP67, 12-30 VDC
- MPN: BCS R08RRE-NOM80C-EP02
- PPN: BAL-BCS012F
CAD
$211.72
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Capacitive sensors for object detection feature a straight-line electrical field. They detect both solid bodies, such as wafers, PCBs, cartons, paper stacks, bottles, plastic blocks and plates, and liquids through container walls or glass or plastic tubes (thickness max. 4 mm).
Documentation & Downloads
Specifications
Additional
| Operating Voltage | 12-30 VDC |
|---|---|
| Approval/Conformity | cULus, CE, WEEE |
| Switching Output | NPN Normally closed (NC) |
| Load Capacitance Max | 0.33 F |
| Rated Operating Current | 50 mA |
| Voltage Drop Static Max | 1.5 V |
| Real Switching Distance | 8 mm |
| Temperature Drift Max | 20 % of Sr [-5 to 55 C] |
| Installation | Flush mounting |
| Ambient Temperature | -25 to 70 C |
| Tightening Torque | 0.2 Nm |
| Housing Material | PP |
| Size | Block style |
| Cable Diameter | 3.40 mm |
| Number of Conductors | 4 |
| MTTF (40 C) | 98 a |
| Switching Frequency | 50 Hz |
|---|---|
| Measuring Range | 1-8 mm |
| Sensitivity | Switching distance teachable |
| No-load Current Max | 12 mA |
| Rated Operating Voltage | 24 VDC |
| Hysteresis Max | 15 % of Sr |
| Repeat Accuracy Max | 5 % of Sr |
| Dimension | 34 x 16 x 8 mm |
| Connection | Cable, 2 m, PUR |
| Storage Temperature | -25 to 85 C |
| Material Sensing Surface | PP |
| Material Jacket | PUR |
| IP Rating | IP67 |
| Conductor Cross-section | 0.14 mm2 |
| Series | R08 |
