ABB

ABB 1SVR405606R7000 CR-P110AC2G Pluggable interface relay 2c/o,A1-A2=110VAC, 250V/8A gold contacts

CR-P110AC2G Pluggable interface relay 2c/o,A1-A2=110VAC, 250V/8A gold contacts
  • MPN: 1SVR405606R7000
  • UPC: 888614251113
  • PPN: ABB-1SVR405606R7000
  • UNSPSC: 39122331

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$18.72/ EA

Description

The CR-P110AC2G pluggable interface relay is suitable for direct mounting on a printed circuit board or use in conjunction with ABB's sockets. This relay operates with a 110 V AC rated control supply voltage and has a 2 c/o (SPDT) output with gold plated contacts rated at 250 V / 8 A. The gold plating ensures contact reliability for low load applications. enabling the possibility of switching multiple circuits with a single input signal. Coupled with a socket, the compact size of this relay offers possibilities to save space within a control panel. Furthermore, with an IP degree of 67, this relay offers complete protection against ingress of dust and airborne particles & protection against water and liquids, up to and including immersion in up to one meter of water. Standard sockets, logical sockets, pluggable function modules, holder and marker are available as accessories.

Specifications

Dimensions

Product Net Width
12.7 mm
Product Net Depth / Length
29 mm
Product Net Height15.7 mm
Product Net Weight0.014 kg

Technical

Function
Pluggable pcb interface relay CR-P
Rated Control Supply Voltage (Us)
110 V AC
Output
2 c/o (SPDT) contacts
Terminal Type
Soldering Pins
Rated Operational Current AC-15 (Ie)
(120 V) 3 A(230 V) 1.5 A
Rated Operational Current DC-13 (Ie)
(24 V) 2 A(250 V) 0.1 A
Degree of Protection
IP67
Standards
IEC/EN 63000IEC/EN 61810-1
Sub-FunctionRelay with gold-plated contacts
Rated Operational Voltage400 V AC
Output Signal250 V / 8 A
Rated Operational Current AC-12 (Ie)(230 V) 8 A
Rated Operational Current DC-12 (Ie)(24 V) 8 A
Rated Insulation Voltage (Ui)400 V
Mounting Position1

Classifications

Object Classification Code
K
eClass
V11.0 : 27371601
ETIM 9EC001437 - Switching relay

Environmental

Ambient Air Temperature
Operation -40 ... +70 °CStorage -40 ... +85 °C
RoHS Status
Following EU Directive 2011/65/EU
Maximum Operating Altitude PermissibleWithout Derating 2000 m

Technical UL/CSA

Maximum Operating Voltage UL/CSA
300 V AC
Flammability According to UL94
V-0
Pilot Duty UL/CSAB300

Ordering

Minimum Order Quantity
10 piece
Customs Tariff Number85364900
