Schneider Electric LT6CT8001 Current transformer, TeSys LT6, 800:1, class 5P accuracy, diameter 10mm
- MPN: LT6CT8001
- PPN: SCH-LT6CT8001
CAD
$1732.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The Schneider Electric TeSys LT6 protection relay is a versatile solution designed to safeguard against various electrical anomalies. From thermal overloads to phase imbalance and earth leakage current, this relay offers comprehensive protection, ensuring the safety and reliability of electrical systems. The front panel features a 7-segment display unit for viewing protection faults, along with intuitive controls such as test and reset pushbuttons, DIP switch, and serial interface, enhancing operational convenience. Additionally, it offers fault and alarm indication via a remote display unit, enhancing monitoring and control capabilities. With communication via bus using Uni-Telway and Jbus/Modbus protocols, it facilitates seamless integration and data exchange, including measurements, logs, and configuration parameters. To complement this system, this current transformer, with a 800:1 ratio and class 5P accuracy, ensures precise and reliable current measurement, further enhancing the functionality of the TeSys LT6 protection relay.
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- Brazil, France, United Kingdom
Depth25 mm
Complementary Attributes
- Maximum Ambient Air Temperature For Operation
- 50 °C
Important Information Attributes
- Persona Type Ids
- LC, OM, OM8, PB, SI
- Market Segmentation Id
- COMMERCIAL, INDUSTRIAL
- Certificate Agency
- IEC 60185, BS 7626
- Local Publishable Date
- 2026-06-27
- Stocking Flag
- Y
- Device Type
- Transformer - current transformer
- Traceability
- No
- Weee Product Category
- 5
- Reach Full Compliance Status
- Reference contains Substances of Very High Concern above the threshold
- Reach Compliance Directive
- Reference contains Substances of Very High Concern above the threshold
- Rohs Eur Status
- Compliant By Exemption
- Rohs Eur Full Compliance Status
- Compliant By Exemption
- With Recycled Cardboard
- Yes
- Product Contributes To Saved And Avoided Emissions
- No
- Tier
- 3
- Function Option
- Standard
- Compatibility Code
- LT6CT
- Device Short Name
- LT6CT
- Energy Efficiency Optimized
- False
- Product Availability
- Non-Stock - Not normally stocked in distribution facility
- Range
- TeSys
- Sustainable Packaging
- No
- Height Nominal
- 107 mm
- [Ui] Rated Insulation Voltage
- 690 V
- Package Weight(Lbs)
- 735.000 g
- Warranty (In Months)
- 18
Persona Type NamesContractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market SegmentationCommercial, Industrial
Local Data StatusPublishable
Return IndicatorN
Stock Policy2
ServiceabilityNo
Weee ScopeIn
Scope PerimeterAt least in Europe
Reach Full Compliance Status IdCONTAINS_SVHC
Rohs Eur In ScopeYes
Rohs Eur Conformity Date1831
China Rohs In ScopeNo
Without Single Use PlasticNo
Tier Id3
Function Option IdSTANDARD
Product Kit IdentifierN
Current Transformer Ratio800/1
Diameter10 mm
Precision Limit Factor15
Product Or Component Typecurrent transformer
ReturnabilityNo
Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Width Nominal95 mm
Nbr. Of Units In Pkg.1
Take-backNo
Customs Code8504314065
Environment Attributes Main
- China Rohs Regulation
- Product out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
- Recycled Metal Content At Cr Level
- 0 %
- Eu Rohs Directive
- Compliant By Exemption
- Packaging Without Single Use Plastic
- No
Take BackNo
Mercury FreeYes
Packaging Made With Recycled CardboardYes
Reach RegulationReference contains Substances of Very High Concern above the threshold
General Attributes
- Product Or Component Type
- current transformer
ETIM
- ETIM 8
- EC002048
ETIM 9EC002048
Contractual Warranty Attributes
- Warranty Period
- 18 months
Warranty18 months
