ABB 1SVR740021R2300 Multifunction Time Relay, 2 c/o, 380-440V AC, Time Range 0.05s-300h
- MPN: 1SVR740021R2300
- UPC: 804325584395
- PPN: ABB-1SVR740021R2300
- UNSPSC: 39122329
CAD
$343.98
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
The CT-MVS.23P is a multifunction electronic time relay from the CT-S timer range. It provides 10 timing functions with 10 time ranges from 0.05 s to 300 h. This time relay operates with a rated control supply voltage of 380 - 440 V AC and has a 2 c/o (SPDT) output with contacts rated at 250 V / 4 A. A control input works with voltage-related (non-floating) triggering. A sealable transparent cover for protection against unauthorized changes is available as accessory. The device offers maintenance free Easy Connect Technology with push-in terminals.
Specifications
Additional
- Control Supply Voltage
- 380 ... 440 V AC
- Contact Rating
- 250 V, 4 A
- Rated Frequency
- 50 Hz, 60 Hz
- Rated Operational Current AC-12
- (230 V) 4 A
- Rated Operational Current DC-12
- (24 V) 4 A
- Rated Impulse Withstand Voltage
- Input Circuit 4 kV, Output Circuit 1 / 2 4 kV
- Mechanical Durability
- 30,000,000 cycles
- Time Functions
- Impulse OFF, Impulse ON, OFF-Delay, ON-Delay, Star-Delta
- Product Net Weight
- 0.133 kg
- Mounting Position
- 1 to 6
- Connecting Capacity
- Flexible 2x 0.5 ... 1.5 mm2 with/without ferrule, Rigid 2x 0.5 ... 1.5 mm2
- Degree of Protection
- Housing IP50, Terminals IP20
- Flammability According to UL94
- V-0
- RoHS Status
- Following EU Directive 2011/65/EU
- Pilot Duty UL/CSA
- B300
- Ambient Air Temperature
- Operation -25 ... +60 C, Storage -40 ... +85 C
- E-Number (Sweden)
- 4033130
- E-Class
- V11.0 : 27371605
- Customs Tariff Number
- 85364900
Output Contacts2 c/o (SPDT) contacts
Time Range0.05 s ... 300 h
Rated Operational VoltageAuxiliary Circuit 250 V
Rated Operational Current AC-15(230 V) 3 A
Rated Operational Current DC-13(24 V) 2 A
Rated Insulation VoltageInput/Output Circuit 500 V, Output Circuit 1 / 2 300 V
Electrical DurabilityAC-12 100,000 cycles
Dimensions (Height x Width x Depth)85.6 mm x 22.5 mm x 103.7 mm
Mounting on DIN RailTH35-7.5 and TH35-15 acc. to IEC 60715
Terminal TypeScrewless Terminals
Pollution Degree3
Overvoltage CategoryIII
StandardsCAN/CSA C22.2 No.14, IEC/EN 63000, IEC/EN 61812-1, UL 508
Contact Rating UL/CSAB300
Short-Circuit Protective DevicesOutput Circuit NC - F Type Fuses 6 A, Output Circuit NO - F Type Fuses 10 A
Minimum Switching Capacity12 V, 10 mA
E-Number (Finland)2712218
ETIM 9EC001439 - Timer relay
