nVent Hoffman E1PBGXM Deep Pushbutton Enclosure, 1PB x 22.5mm, Steel, NEMA Type 12, IP65
- MPN: E1PBGXM
- UPC: 783510135263
- PPN: HOF-E1PBGXM
- UNSPSC: 39121326
CAD
$147.54
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Deep Pre-cut pushbutton enclosures provide extra wiring space to house and protect components. This Deep Pushbutton Enclosures Type 12, E1PBGXM item measures 1PB x 22.5mm with a material of Steel colored Gray.
Features
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on cover
- Grounding nut in body of enclosure
- Oil-resistant gasket
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during installation
- External welded-on mounting brackets for easy installation
- Factory stamped 4-way pushbutton holes
- 22.5-mm size holes
Documentation & Downloads
Specifications
Key Specifications
- BABA
- Contact Manufacturer
- Width (W)
- 70
- Protection Rating
- NEMA Type 12
- Finish
- Powder Coated
- Thickness (T)
- 1.9
- Mounting (G x H)
- 95 x 48
- IP Rating
- IP65
- Number of Holes
- 1
- Size
- 1PB x 22.5mm
- NEMA Rating
- 12 Indoor, dust-resistant
Height (H)83
Depth (D)89
Product FamilyPushButton
Color CodeANSI 61
Hole Quantity1
Overall Dimensions (L x W)108 x 75
Weight1.5
MaterialSteel
ColorGray
