nVent Hoffman E2PBGXM Deep Pushbutton Enclosure 2PB x 22.5mm Gray Steel, NEMA Type 12, IP65
- MPN: E2PBGXM
- UPC: 783510135270
- PPN: HOF-E2PBGXM
- UNSPSC: 39121326
CAD
$170.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Deep Pre-cut pushbutton enclosures provide extra wiring space to house and protect components. This Deep Pushbutton Enclosures Type 12, E2PBGXM item measures 2PB x 22.5mm with a material of Steel colored Gray.
Features
- Seams continuously welded and ground smooth
- Captivated cover screws thread into sealed wells
- Bonding provision on cover
- Grounding nut in body of enclosure
- Oil-resistant gasket
- Enclosures with more than one column of pushbutton holes have internal detachable hinge to hold cover open during installation
- External welded-on mounting brackets for easy installation
- Factory stamped 4-way pushbutton holes
- 22.5-mm size holes
Documentation & Downloads
Specifications
Key Specifications
| BABA | Contact Manufacturer |
|---|---|
| Width (W) | 70 |
| Protection Rating | NEMA Type 12 |
| Finish | Powder Coated |
| Thickness (T) | 1.9 |
| Mounting (G x H) | 143 x 48 |
| IP Rating | IP65 |
| Number of Holes | 2 |
| Size | 2PB x 22.5mm |
| NEMA Rating | 12 Indoor, dust-resistant |
| Height (H) | 130 |
|---|---|
| Depth (D) | 89 |
| Product Family | PushButton |
| Color Code | ANSI 61 |
| Hole Quantity | 2 |
| Overall Dimensions (L x W) | 155 x 75 |
| Weight | 2 |
| Material | Steel |
| Color | Gray |
