Bussman C10G20 Low Voltage Cylindrical Fuse 500V 20A 120kAIC Ceramic Body Ferrule End

MPN: C10G20
UPC: 051712754293
PPN: BUS-C10G20

Spec sheet

Compare

Loading compare button...

In Stock

Company Stock:

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$21.25/ EA

Qty:

Loading add to cart quantity...

Specifications

Fuse Indicator: CHM fuse holder

Construction Size: 10 x 38 mm

Quantity: 10 per package

Release Characteristic: Other

Frequency Rating Maximum: 45 HZ

Fuse Type: Cylindrical

Fuse Shape: cylindrical

Amperage Rating Numeric: 20 A

Frequency Rating Minimum: 62 HZ

Voltage Rating: 500V

Voltage Rating Numeric: 500 V

Packaging Type: Standard

Interrupt Rating120 kAIC

ConnectionFerrule end X ferrule end

Material TypeCeramic body, Silver-plated copper endcap

Amperage Rating20A

Utilization CategorygL/gG (cable protection/equipment protection)

Typefuse

Breaking Capacity120 KA

With StrikerNo

ClassClass C gL/gG

Applicationfor industrial applications

Voltage TypeAC

General

UPC: 051712754293

Product Length/Depth: 38 MM

Product Width: 10 MM

Warranty: 1 year limited

Certifications: IEC 60269

EAN5027590493475

Product Height38 MM

Product Weight38 G

CompliancesContact factory
