Hubbell Wiring Device-Kellems HBL460MIF7W IEC Pin and Sleeve Female Receptacle 60A 3-Phase 480V AC, Watertight
- MPN: HBL460MIF7W
- UPC: 783585406022
- PPN: HBL-HBL460MIF7W
- UNSPSC: 39121406
CAD
$3985.69
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Heavy Duty IEC Pin and Sleeve Industrial Grade Female Fused Mechanically Interlocked Receptacle, 60A 3-Phase Delta 480V AC, 3-Pole 4-Wire Grounding, Terminal
Features
- Replaceable spring-loaded receptacle liftcover with gasket
- Removable door for ease of wiring and installation
- Plug-Check™ mechanism to detect the presence of plug
- Watertight
Specifications
Key Specifications
| Country of Origin | Italy |
|---|---|
| Width | 12.300 in |
| Performance | Electrical - Current Interrupting - Certified for current interrupting at full rated current and voltage;Electrical - Dielectric Voltage - Withstands 3,000V AC Min;Electrical - Max Working Voltage - 600V AC;Environmental - Flammability - UL94-5VA and V-0 Classification;Environmental - Ingress Protection - IP66 Suitability;Environmental - Operating Temperatures - Max. Continuous +75°C;Min. Continuous -40°C;Environmental - UV Resistance - All materials are UV stabilized;Mechanical - Impact Resistance - In accordance with UL 746C;Mechanical - Mounting - External adjustment feet;Mechanical - Terminal Identification - In accordance with UL, CSA and international conventions |
| Application | High Ampacity Connections |
| Environmental Conditions | Watertight |
| Number of Poles | 3-Pole |
| Phase | Three Phase |
| Standard | CSA Certified;UL Listed for US and Canada |
| Voltage Rating | 3 Phase 480 VAC |
| Wire Size | #8 AWG to #2 AWG |
| Weight | 18.45 lb. |
| General Literature Asset 1 Display Text | Circuit-Lock® Rounded Sloped Top Motor Disconnects |
| General Literature Asset 3 Display Text | Improved Short Circuit Current Ratings (SCCR) |
| Display Size | Standard Sized Product |
| Number Of Poles | 3-Pole |
| Style | Standard Service |
| Description - Invoice | PS, IEC, MECHINT, 3P4W, 60A 3P 480V,FUSE |
| Harmonization Code | 8537109170 |
| MSDS Flag | No |
| Sub Class Code | A12A210 |
| Current Rating | 60 A |
| Series | Fused |
| BOX SIZE | 9.200x20.400x12.300 (in) |
| Carton - Number of Sub Packs | 1 |
| Carton - SCC-14 Next Lower Level Sub Pack | 00783585406022 |
| Case Weight | 18.450 lb. |
| Lowest Level UOM | Each |
| Pallet Height | 46.000 in |
| Pallet Weight | 645.750 lb. |
| NAICS Code | 335931A104 |
| Current / Amperage Rating | 60 A |
|---|---|
| Industry Standard(s) | CSA Certified;UL Listed for US and Canada |
| Amperage Rating | 60 A |
| Color | Red |
| NEMA Rating | Non-NEMA |
| Number of Wires | 4-Wire |
| Special Features | Watertight |
| Type | Mechanical Interlock |
| Wattage | 28800 W |
| Voltage Rating Description | 3 Phase 480 VAC |
| Engineering Drawing 1 Display Text | HBL460MIF7W AutoCAD Drawing |
| General Literature Asset 2 Display Text | Circuit-Lock® Motor Disconnects |
| Connectivity | Pressure Terminal Screws |
| Nema Rating | Non-NEMA |
| Number Of Wires | 4-Wire |
| Class Code | A12 |
| Freight Class Code | 06168002 |
| Image Actual Or Representative | A |
| Replaced Catalog Number | 460MIF7W |
| Material - Mounting Hardware | Screw Mounting |
| Material | Thermoplastic |
| Base Unit of Measure | EA |
| Carton - Gross Weight per Pack | 18.500 lb. |
| Carton - Pack Description | Carton |
| Carton - Total Units | 1 |
| Each - Pack Description | Each |
| Pallet - GTIN - Package | 70783585406021 |
| Pallet Length | 48.000 in |
| Pallet Width | 40.000 in |
