Square D 9001KR8P35LRRH25 Harmony Illuminated Push Button 30 mm Red Mushroom 41 mm LED 24-28V
- MPN: 9001KR8P35LRRH25
- UPC: 785901289739
- PPN: SCH-9001KR8P35LRRH25
CAD
$314.43
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
The Harmony illuminated push button from Schneider Electric combines functional design with reliable performance. This 30 mm red mushroom button is ideal for a variety of automation and control applications, offering a distinct visual cue for ease of operation. With an integrated LED that operates at 24-28V, it ensures clear visibility in any environment, enhancing safety and usability. Whether you're designing control panels or upgrading existing systems, this push button stands out as a dependable choice for pilot devices.
Documentation & Downloads
Specifications
Additional
- Rated Operational Current
- 10 A, AC-15; 10 A, DC-13
- Operator Position Information
- 3 positions
- Mounting Diameter
- 30 mm (1.18 in)
- Operator Profile
- mushroom Ø 41 mm
- Contacts Type and Composition
- 1 NC late break + 1 NC
- Light Source
- LED
- Light Source Color
- red
- Mercury Free
- yes
- RoHS Exemption Information
- yes
- Reach Regulation
- Contains SVHC above threshold
- Country of Origin
- Mexico
Rated Supply Voltage24...28 V
Contact Operationlate-break
Size30 mm
Type of Operatorpull: spring return, center: stay put, push: spring return
Bezel Materialmetal
Cap/Operator Colorred
Product CertificationsCSA LR 25490 class 3211 03, NEMA 1/2/3/3R/4/6/12/13, UL listed file E42259, CE
Eu Rohs DirectivePro-active compliance (out of EU RoHS legal scope)
WeeeEU market compliant disposal
Sustainable Offer StatusGreen Premium
Device Presentationcomplete product
