Telemecanique Sensors XSDM600539H7 Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 24...240VAC/DC, terminals
Telemecanique Sensors XSDM600539H7 Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn60mm, 24...240VAC/DC, terminals
- MPN: XSDM600539H7
- PPN: TES-XSDM600539H7
- UNSPSC: 39122230
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$559.57/ EA
Description
This product is part of the XS range, an offer of inductive proximity sensors. This general purpose inductive proximity sensor in a form 80mm x 80mm x 40mm design and fixed body. It is non flush mountable and in a frontal detection face. It supports 60mm nominal sensing distance and 1 NO or 1 NC programmable discrete output. The inductive proximity sensor with a rated supply voltage of 12V to 240V AC/DC. It is furnished with screw clamp terminals for electrical connection. It is an IP67 rated product. The enclosure is made of plastic. Its dimensions are 80mm (width) x 40mm (depth) x 100mm (height). It is suitable for railway, mobile equipment, material handling/conveying/logistics, material working/machine tools, packaging, robotics, food and beverage industries. This product is certified by CCC, CE, CSA and UL. Inductive sensors come in flush and non flush versions, M8, M12, M18, M30 short and long bodies cylindrical forms, standard cubic, rectangular and flat forms. The inductive proximity sensors for non contact sensing of metal objects up to 60mm. It is designed for use in industrial applications relating to presence detection.
Specifications
Environment
- Product Certifications
- UL || CSA || CCC
Ambient Air Temperature For Operation-25-70 °C
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP071001EN
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
California Proposition 65WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Complementary
- Height
- 100 mm
- Marking
- CE
- Switching Frequency
- <= 10 Hz
- Switching Capacity In Ma
- 5...100 mA DC || 5...500 mA AC
- Width
- 80 mm
- Depth
- 40 mm
Cable Entry1 entry tapped for 1/2" NPT cable gland
Materialplastic
Detector Flush Mounting Acceptancenon flush mountable
Detection Facefrontal
Front Materialplastic
Output Circuit TypeAC/DC
Specifications
- Electrical Connection
- screw-clamp terminals
- Discrete Output Function
- 1 NO or 1 NC programmable
- Range Of Product
- Telemecanique Inductive proximity sensors XS
- Size
- 40 mm
- Ip Degree Of Protection
- IP67
- Body Type
- fixed
- Sensor Type
- inductive proximity sensor
- Enclosure Material
- Plastic
[Us] Rated Supply Voltage12...240 V AC/DC
Type Of Output Signaldiscrete
Sensor NameXSD
Wiring Technique2-wire
Series Namegeneral purpose
[Sn] Nominal Sensing Distance60 mm
Sensor Designform 80 x 80 x 40
