Balluff BNI IOL-310-000-K025-001 IO-Link Sensor/Actuator Hub 16x PNP, IP20, 79 x 33.6 x 84 mm
Balluff BNI IOL-310-000-K025-001 IO-Link Sensor/Actuator Hub 16x PNP, IP20, 79 x 33.6 x 84 mm
- MPN: BNI IOL-310-000-K025-001
- PPN: BAL-BNI007R
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$201.05/ EA
Description
The IO-Link Sensor/Actuator Hub from Balluff is a robust and versatile solution designed to streamline your automation processes. This compact hub features 16 digital outputs with PNP configuration, allowing for efficient control of various sensors and actuators. With an IP20 rating and dimensions of 79 x 33.6 x 84 mm, it is well-suited for installation in diverse environments, maintaining reliable operation within an ambient temperature range of -20 to 50 °C.
Equipped with pluggable connections that eliminate the need for terminals, this hub simplifies installation and maintenance. It supports a data transfer rate of 38.4 kBaud and is capable of processing data in 2 bytes, ensuring swift communication between devices. With a switching current of 350 mA per output and a total current capacity of 1.0 A for sensors and 1.6 A for actuators, this hub is engineered for high performance and reliability in demanding applications.
Specifications
Specifications
- Country of Origin
- Hungary
- Operating voltage Ub
- 18...30.2 VDC
- Connection (supply voltage IN)
- Pluggable without terminals
- Digital inputs
- 16x PNP, Type 2
- Configurable inputs/outputs
- yes
- Current sum UA, actuator
- 1.6 A
- Housing material
- PA 6.6, UL94V-0
- Ambient temperature
- -20...50 °C
- Data transfer rate
- COM2 (38.4 kBaud)
- Process data in
- 2 bytes
InterfaceIO-Link 1.0
Connection (COM 1)Pluggable without terminals, 4-pin
Connection slotsPluggable without terminals
Digital outputs16x PNP
Current sum US, sensor1.0 A
Switching current16x 350 mA
Dimension79 x 33.6 x 84 mm
IP ratingIP20
Process data cycle min.12 ms
Process data out2 bytes
