Telemecanique Sensors ZC2JC16 Limit switch body, Limit switches XC Standard, ZC2J, fixed, without display, 1C/O, -40...70 °C
- MPN: ZC2JC16
- PPN: TES-ZC2JC16
- UNSPSC: 39122213
CAD
$106.62
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Limit switch body, Limit switches XC Standard, ZC2J, fixed, without display, 1C/O, -40...70 °C
Documentation & Downloads
Specifications
Key Specifications
- Series Name
- standard format
- Body Type
- fixed
- Contact Operation
- snap action
- Associated Head
- ZC2JE096 || ZC2JE026 || ZC2JE666 || ZC2JE036 || ZC2JE646 || ZC2JE706 || ZC2JE636 || ZC2JE616 || ZC2JE656 || ZC2JE016 || ZC2JE056 || ZC2JE626
- Cable Entry
- 1 tapped entry for Pg 13.5 cable gland (included)
- Product Compatibility
- XC2J
- Device Short Name
- ZC2J
Contacts Type And Composition1 C/O
Range Of ProductTelemecanique Limit switches XC Standard
Contacts Materialsilver plated contacts
Body Materialmetal
Product Or Component Typelimit switch body
Number Of Steps1 1 position
Number Of Poles1
Complementary
- Height
- 81-81 mm
- Terminals Description Iso N°1
- (11-12)NC || (13-14)NO
- [Ui] Rated Insulation Voltage
- 500 VIEC 60947-1 contact block || 300 VCSA C22.2 No 14 contact block
- Minimum Actuation Speed
- 0.01 m/min
- Electrical Connection
- screw-clamp terminals 1 x 0.5...2 x 2.5 mm²
- Width
- 40 mm
- Local Display
- without
- Maximum Resistance Across Terminals
- 0.25 mOhm IEC 60255-7 category 3
Electrical Durability5000000 cycles, DC-13 120 V, 4 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 24 V, 10 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 48 V, 7 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
Short-Circuit Protection10 A cartridge fuse gG
Positive Openingwithout
[Ie] Rated Operational Current3 A 240 V, AC-15, A300 EN/IEC 60947-5-1 appendix A || 0.27 A 250 V, DC-13, Q300 EN/IEC 60947-5-1 appendix A
[Ithe] Conventional Enclosed Thermal Current10 A
Depth41 mm
Net Weight0.355 kg
Environment
- Ambient Air Temperature For Storage
- -40-70 °C
- Ambient Air Temperature For Operation
- -40-70 °C low temperature
- Ip Degree Of Protection
- IP65
Environmental Characteristiclow temperature
Ik Degree Of ProtectionIK08
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP110614EN
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- California Proposition 65
- WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationReference contains Substances of Very High Concern above the threshold
