Telemecanique Sensors ZCMD61C12 Limit switch body, Limit switches XC Standard, ZCMD, 1NC+1 NO, gold, snap action, connection, M12
- MPN: ZCMD61C12
- PPN: TES-ZCMD61C12
- UNSPSC: 39122213
CAD
$201.48
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Limit switch body, Limit switches XC Standard, ZCMD, 1NC+1 NO, gold, snap action, connection, M12
Documentation & Downloads
Specifications
Key Specifications
- Series Name
- standard format
- Body Type
- fixed
- Contact Operation
- snap action
- Body Material
- zamak
- Design
- miniature
- Number Of Poles
- 2
Contacts Type And Composition1 NC + 1 NO
Range Of ProductTelemecanique Limit switches XC Standard
Associated HeadZCE01 || ZCE13 || ZCE02 || ZCE67 || ZCE63 || ZCE24 || ZCE08 || ZCE07 || ZCE64 || ZCE21 || ZCEF0 || ZCE10 || ZCE29 || ZCE66 || ZCEG1 || ZCE14 || ZCE27 || ZCE65 || ZCE28 || ZCE11 || ZCEF2 || ZCE06 || ZCE62 || ZCE09
Product Or Component Typelimit switch body
Device Short NameZCMD
Complementary
- Height
- 50-50 mm
- Short-Circuit Protection
- 4 A cartridge fuse gG
- Positive Opening
- without
- Contacts Insulation Form
- Zb
- Electrical Connection
- male connector M12, 5 pins
- [Ithe] Conventional Enclosed Thermal Current
- 4 A
- Depth
- 16 mm
- Net Weight
- 0.065 kg
- Maximum Resistance Across Terminals
- 25 mOhm IEC 60255-7 category 3
Electrical Durability5000000 cycles, DC-13 24 V, 3 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C || 5000000 cycles, DC-13 48 V, 2 W 60 cyc/mn 0.5 IEC 60947-5-1 appendix C
[Ui] Rated Insulation Voltage60 V 3)IEC 60947-5-1
Minimum Actuation Speed0.01 m/min
[Ie] Rated Operational Current0.22 A 50 V, DC-13 EN/IEC 60947-5-1 appendix A || 3 A 50 V, AC-15 EN/IEC 60947-5-1 appendix A
Contacts Materialgold plated contacts
Width30 mm
Product CompatibilityXCMD
[Uimp] Rated Impulse Withstand Voltage0.8 kV IEC 60664 || 0.8 kV IEC 60947-1
Environment
- Ambient Air Temperature For Storage
- -40-70 °C
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Circularity Profile
- ENVEOLI110612EN
- Mercury Free
- Yes
- Sustainable Offer Status
- Green Premium product
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Rohs Exemption InformationYes
Environmental DisclosureENVPEP110612EN
Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)
