Schneider Electric CQO160M200PC QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1

  • MPN: CQO160M200PC
  • UPC: 785901785613
  • PPN: SCH-CQO160M200PC
  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below

    • CAD

    $375.03

    / EA

    Available to Order

    Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST

    Available To Ship Immediately:0

    Loading dialog...

    Looking to buy a large quantity?

    To View Branch Inventory And Your Custom Pricing

    Spec sheet

    Description

    QO Loadcentres offer premium features by allowing QO breakers, ground fault interrupters, arc fault interrupters, and surge arresters to be installed inside. QO Loadcentres are designed for residential and industrial use to protect electrical systems, equipment, and people. They are available in both traditional and plug on neutral configurations. There is 3 types of mains available. There is main circuit breaker, main lugs, and generator panel. Single and three phase options are available. The bus bars are tin plated copper and are shielded. Indoor and outdoors enclosures are an option. QO Loadcentres enable the use of a full complement of accessories. This 1 phase loadcentre has 60 spaces and 120 circuits. This system provides 200A main breaker in a NEMA 1 enclosure. It also includes plug on neutral, combination cover, and is CSA rated.

    Features

    • This massive loadcentre provides 60 full-sized slots accommodating up to 80 circuits through the integration of space-saving tandem breakers. For residential contractors and custom home builders, this expansive capacity effortlessly handles power-heavy modern upgrades like multiple EV chargers, heat pumps, and hot tubs without requiring a secondary sub-panel.
    • Engineered with an advanced Plug-on Neutral (PoN) rail system, this chassis allows combination arc fault (CAFCI) and ground fault (GFCI) breakers to snap directly onto the neutral bar. This design eliminates the time-consuming process of wiring pigtails, cutting down gutter clutter by up to 50% and simplifying future troubleshooting for a clean, professional finish.
    • Built with premium, shielded, tin-plated copper busbars, this interior structure ensures maximum electrical conductivity and superior thermal resilience. The specialized tin plating actively shields the copper rails from galvanic corrosion and oxidization, providing long-term reliability and maintaining lower operating temperatures under continuous 200A loads.
    • The heavy-duty NEMA 1 indoor sheet steel enclosure is fully invertible, meaning the box can be rotated 180 degrees to easily accommodate top or bottom main service entrance feeds. This installation flexibility eliminates the need to route thick, expensive service entrance cables into tight configurations, saving substantial material costs and reducing installation labor.
    • Equipped with a factory-installed 200A main circuit breaker boasting a high 22 kA short-circuit current rating (kAIC), this panel delivers robust overcurrent defense against severe fault currents. This high interrupting threshold safeguards delicate home electronics and charging equipment from upstream line faults, while the split neutral bars feature backed-out screws to accelerate wire termination.

    Documentation & Downloads

    Specifications

    Key Specifications

    Country of OriginUnited States
    Depth95 mm

    Complementary Attributes

    Line Rated Current200 A

    Important Information Attributes

    Carbon Footprint Of The Distribution Phase [A4]3.833325, 4 kg CO2 eq.
    Carbon Footprint Of The Installation Phase [A5]0.0089478794, 0 kg CO2 eq.
    Carbon Footprint Of The Use Phase [B2 B3 B4 B6]0.1 kg CO2 eq., 0.087341
    Local Publishable Date2026-07-14
    Stocking FlagN
    Weee ScopeIn
    Scope PerimeterAt least in Europe
    Reach Full Compliance StatusReference contains Substances of Very High Concern above the threshold
    Reach Compliance DirectiveReference contains Substances of Very High Concern above the threshold
    Rohs Eur StatusCompliant By Exemption
    Rohs Eur Full Compliance StatusCompliant By Exemption
    With Recycled CardboardNo
    Product Contributes To Saved And Avoided EmissionsNo
    Persona Type NamesContractor
    Tier1
    Function OptionStandard
    Market SegmentationResidential
    Awg Gauge14 AWG...1/0 AWG copper12 AWG...1/0 AWG aluminium
    Electrical Connectionlugs
    Energy Efficiency OptimizedFalse
    Load Center TypePoN Convertible Mains (breaker)
    Number Of Circuits80
    Number Of Tandem Circuit Breakers20
    Product AvailabilityStock - Normally stocked in distribution facility
    Range Of ProductQO
    Software VersionEIME v5.9.4
    Sustainable PackagingNo
    Total Lifecycle Carbon Footprint87 kg CO2 eq.
    Pep CodeENVPEP2212001EN
    Pep Verification Date2023-08-01
    Psr VersionPSR-0005-ed2-EN-2016 03 29
    Data Sourceextrapolated product
    Functional-unit Quantity1
    Reference Lifetime In Y20
    Energy Model - Installation [A5]Electricity mix; AC; consumption mix, at consumer; 120V; US
    Energy Model - End Of Life [C1-c4]Electricity mix; AC; consumption mix, at consumer; 120V; US
    Height Nominal1048 mm
    Certificate AgencyCSA
    Short-circuit Current22 kA
    Package Weight(Lbs)11.34 kg
    Warranty (In Months)18
    Depletion Of Abiotic Resources - Fossil Fuels (Mj) Operational Energy Use [B6]1.0634
    Total Use Of Primary Energy During The Life Cycle (Mj) Operational Energy Use [B6]1.1758
    Water Pollution (M3) Manufacturing [A1-a3]3900.15
    Customs Code8537109150
    Carbon Footprint Of The End-of-life Phase [C1 To C4]1 kg CO2 eq., 1.1889727941
    Carbon Footprint Of The Manufacturing Phase [A1 To A3]82 kg CO2 eq., 81.8314411765
    Local Data StatusPublishable
    Return IndicatorY
    Stock Policy2
    Weee Product Category5
    Eoli Availability DisplayNo need of specific recycling operations
    Reach Full Compliance Status IdCONTAINS_SVHC
    Rohs Eur In ScopeYes
    Rohs Eur Conformity Date2532
    China Rohs In ScopeNo
    Without Single Use PlasticNo
    Persona Type IdsLC
    Tier Id1
    Function Option IdSTANDARD
    Market Segmentation IdRESIDENTIAL
    Product Kit IdentifierN
    Cover Typecombination flush/surface cover
    Enclosure Materialwelded sheet steel
    Installation Directionvertical
    Materialtin plated copper: busbar
    Number Of Spaces60
    Phase1 phase
    Product Or Component TypeLoad Center
    ReturnabilityYes
    Surface Finishbaked enamel Gray
    Tightening TorqueCover 20 lb.in
    Weee LabelThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    Database Version2022-01
    Pcr VersionPCR-ed3-EN-2015 04 02
    Type Of Verification For The PepIndependent external review
    Functional-unit DescriptionProtect persons during 20 years against direct contact with live parts and allow grouping monitoring, control and protection devices in a single enclosure or a cabinet having the following dimensions 858mm×361mm×95mm, comply with UL 67 and CSA22.2 with an available offer:& 10•Suitable for use on 120/240 Vac and 48 Vdc systems& 10•Rated 30 to 400 amps 2 to 60 circuits& 10•3/4" circuit breaker width& 10•Single and three phase
    Functional-unit Unitunit
    Energy Model - Manufacturing [A1-a3]Energy model used: Lexington
    Energy Model - Use [B6]Electricity mix; AC; consumption mix, at consumer; 120V; US
    Recyclability Potential In %88
    Width Nominal362 mm
    [Ue] Rated Operational Voltage240 V AC
    Nbr. Of Units In Pkg.1
    Take-backNo
    Air Pollution (M3) Operational Energy Use [B6]7.4172
    Total Use Of Non-renewable Primary Energy Resources (Primary Energy And Primary Energy Resources Used As Raw Materials) (Mj) Operational Energy Use [B6]1.1052
    Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Operational Energy Use [B6]1.1052
    Water Pollution (M3) Operational Energy Use [B6]4.3059

    Environment Attributes Main

    China Rohs RegulationProduct out of China RoHS scope , Product out of China RoHS scope. Substance declaration for your information.
    Take BackNo
    Mercury FreeYes
    Environmental DisclosureENVPEP2212001EN
    Nema Degree Of ProtectionNEMA 1 indoor enclosure
    Packaging Without Single Use PlasticNo
    Pep CodeENVPEP2212001EN
    Pcr VersionPCR-ed3-EN-2015 04 02
    Type Of Verification For The PepIndependent external review
    Ambient Air Temperature For Operation-5 °C, -5 °C, 40 °C
    Recycled Metal Content At Cr Level0 %
    Carbon Footprint86.95002785
    Eu Rohs DirectiveCompliant By Exemption
    Packaging Made With Recycled CardboardNo
    Reach RegulationReference contains Substances of Very High Concern above the threshold
    Pep Verification Date2023-08-01
    Psr VersionPSR-0005-ed2-EN-2016 03 29

    General Attributes

    Phase1 phase
    Range Of ProductQO
    Product Or Component TypeLoad Center

    ETIM

    ETIM 8EC000214
    ETIM 9EC000214
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
    QO Load Center, 1 Phase, 200A Main Breaker, 60 Spaces, Indoor NEMA 1
