Burndy YAZ8C2TC10 Long Length Copper Hylug Terminal, 2 Holes, 8 AWG, 35 kV, Red
- MPN: YAZ8C2TC10
- UPC: 781810196960
- PPN: BUR-25015927
CAD
$14.49
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Cu Tubing Hylug (2 Hole Code), 2 Holes with Inspection Window, #8 AWG Code,23 Navy, 600V-35kV, #10 stud, Long, Compression, 0.21 in BCD, Red.
Documentation & Downloads
Specifications
Dimensions
- Dimension - B Length fraction
- 3/4 in
- Dimension - Bolt Hole Size inch
- 0.20 in
- Dimension - Hole Size mm
- 5 mm
- Dimension - Length Overall inch
- 2.07 in
- Dimension - Outside Diameter inch
- 0.27 in
- Dimension - Strip Length inch
- 7/8
- Dimension - Z inch
- 0.28 in
Dimension - B Length inch0.75 in
Dimension - Hole Size inch0.21 in
Dimension - L Length Overall mm53 mm
Dimension - N inch0.25 in
Dimension - Pad Width inch0.41 in
Dimension - Stud Size inch#10
Physical Attribute - Tongue AngleStraight
Certifications and Compliance
- Certification - CSA Approved
- Yes
- Certification - UL Recognized
- No
- Standards - RoHS Compliance Status
- CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes
Conductor Related
- Conductor - Copper Str Navy Size
- 23 (7) Navy
- Conductor - Material
- Copper
Conductor - Copper Str Size8 AWG
General
- Application
- For Code Conductor
- Connector Type
- Terminal
- Feature - Barrel Style
- Skived
- Material
- Copper
- Physical Attribute - Tongue Type
- Standard
- Plating Type
- Tin - Electro Plated
- Trade Name
- HYLUG™
- UPC
- 781810196960
Color CodeRed
Die Index49
Feature - Barrel TypeLong
Physical Attribute - Number of Holes2
PlatedY
Sub BrandHYLUG
TypeLong Barrel, Skive, Tin Plated
UPC 12 Digit7818101969600
Electrical Ratings
- Rating - KVA
- 35 kV
- Voltage - Maximum
- 35000
Rating - Minimum Voltage600
Logistics
- Minimum Pack Quantity
- 1
