Pass & Seymour 7862R Manual Control Switch 2-Pole 60A 600V NEMA 3R Enclosure
- MPN: 7862R
- UPC: 785007078619
- PPN: P-S-7862R
CAD
$299.30
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Manual Control Switch 2-Pole 60A 600V NEMA 3R Enclosure
Features
- High horsepower rating, up to 3HP for heavy-duty applications
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
- Compact design provides ease of installation
- Box lug terminals. Single piece moveable and stationary contact arms with oversized silver cadmium buttons provides excellent continuity and long life
- Made in USA
- Wire pockets and thick wall arc barriers. Cold-rolled steel NEMA 3R enclosure with polyester urethane finish conforms to OSHA lockout requirements
- Type 3R enclosure has 2-1/2 inch, 3/4 inch, and 1 inch concentric knockouts on bottom
- Accepts #4 AWG
- cULus listed
Documentation & Downloads
Specifications
Key Specifications
- Depth
- 1.66 in
- Height
- 3.75 in
- Finish
- Matte
- Country of Origin
- United States
- Load Type
- CFL
- Amperage
- 60.0 A
- Voltage
- 600.0 V
- Number of Gangs
- 1
- Switch Type
- Toggle
- Indoor/Outdoor
- Indoor
- Enclosure Type
- NEMA 3R
- Mounting Type
- Wall Box
- Type
- Manual Controller
- Wiring Location
- Bottom
- Load Rating
- 60 A @ 600 VAC
- Application Sector
- Commercial
- Horsepower Rating
- 3 HP @ 120 VAC
- Wire Connection Type
- Screw Terminals
- Maximum Horsepower Rating
- 3 HP @ 120 VAC
- Special Features
- Compact design, 2pt contact arms, heavy duty zinc plated steel strap, oversized silver alloy contacts
ColorGray
Width1.74 in
MaterialThermoplastic
Product LinePass & Seymour
Load TypeLED
Load TypeXenon
Load TypeHalogen
StandardUL Listed
Load TypeUniversal
Load TypeFluorescent
Load TypeIncandescent
Number of Switches1.0
Wall Plate IncludedNo
Requires Neutral WireYes
Number of PolesDouble Pole
Application SectorIndustrial
Connection LocationBack and Side
Warranty Type1-Year Limited Warranty
Terminal Accommodation#14 AWG - #10 AWG
