Square D QOB225H Mini Circuit Breaker 25A 2 Pole 240VAC 10kA Bolt-On
Square D QOB225H Mini Circuit Breaker 25A 2 Pole 240VAC 10kA Bolt-On
- MPN: QOB225H
- UPC: 785901727675
- PPN: SCH-QOB225H
In Stock
Company Stock:
00
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$263.75/ EA
Description
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 25A at 240VAC. This unit provides 10kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
Specifications
- Current Rating
- 25 A
- Voltage Rating
- 120/240 V AC 50/60 Hz
- Circuit Breaker Type
- standard
- Wire Size
- AWG 14...AWG 8 copper or aluminum
- Height
- 76 mm (2.99 in)
- Depth
- 74 mm (2.91 in)
- Certifications
- UL listed, CSA certified
- Compliance
- Eu RoHS Compliant with Exemptions, REACH, Mercury Free, Toxic Heavy Metal Free, China RoHS
- Electrical Connection
- pressure plate
- Range Of Product
- QO
Number of Poles2P
Interrupt Rating10 kA
Mounting Typebolt-on
Tightening Torque4.6 N.m
Width38 mm (1.50 in)
Net Weight0.277 kg (0.61 lb)
Ambient Temperature Rating40 °C (104 °F)
Warranty18 months
Circuit Breaker ApplicationHACR rated
