Schneider Electric VW3E704000000 Profibus DP Communication Module, RS485, 12Mbps, IP20
- MPN: VW3E704000000
- PPN: SCH-VW3E704000000
CAD
$1771.38
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This product is part of the Modicon LMC078 range, an offer of Profibus DP communication modules for motion controllers. This Profibus DP communication module features a slave access and RS485 physical interface. It is a communication module supports 12Mbps transmission rate. It is integrated with 1 female D-sub DE-09 connector. It is an IP20 rated product. It weighs 0.08kg. This product is certified by CE, CSA and CULus. It meets CSA C22.2 No 142, EN/IEC 61131-2 zone B and UL 508 standards. It is compatible with Modicon LMC078 motion controllers and PacDrive LMC Eco controllers.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | Brazil, Germany, France |
|---|
Complementary Attributes
| Integrated Connection Type | Profibus DP - 1 female SUB-D 9 12 Mbit/s |
|---|
Important Information Attributes
| Persona Type Ids | EU, OM |
|---|---|
| Certificate Agency | cULus, CSA, CE |
| Local Publishable Date | 2026-01-12 |
| Stocking Flag | Y |
| Serviceability | No |
| Weee Scope | Out |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 3 |
| Function Option | Advanced |
| Market Segmentation | Industrial |
| Marking | CE |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Range Of Product | Modicon LMC078 |
| Shock Resistance | 100 m/s² |
| Vibration Resistance | 10 m/s² direct mounting |
| Package Weight(Lbs) | 104.000 g |
| Warranty (In Months) | 18 |
| Persona Type Names | End User, Original Equipment Manufacturer |
|---|---|
| Local Data Status | Publishable |
| Return Indicator | Y |
| Stock Policy | 2 |
| Traceability | No |
| Scope Perimeter | At least in Europe |
| Without Single Use Plastic | No |
| Tier Id | 3 |
| Function Option Id | ADVANCED |
| Market Segmentation Id | INDUSTRIAL |
| Product Kit Identifier | N |
| Method Of Access | master/slave |
| Product Or Component Type | Profibus DP communication module |
| Returnability | Yes |
| Sustainable Packaging | No |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8517620090 |
Environment Attributes Main
| Ambient Air Temperature For Storage | -25-70 °C, -25-70 °C |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Ip Degree Of Protection | IP20IEC 61131-2 |
| Packaging Made With Recycled Cardboard | Yes |
| Product Compatibility | motion controller |
| Take Back | No |
|---|---|
| Ambient Air Temperature For Operation | 5-55 °C |
| Operating Altitude | 0...6561.68 ft (0...2000 m) |
| Packaging Without Single Use Plastic | No |
| Relative Humidity | 5-95 % without condensation |
General Attributes
| Product Or Component Type | Profibus DP communication module |
|---|
| Range Of Product | Modicon LMC078 |
|---|
ETIM
| ETIM 8 | EC002025 |
|---|
| ETIM 9 | EC002025 |
|---|
