Weidmuller 8973460000 MOS SUPPLY
- MPN: 8973460000
- PPN: WDM-8973460000
CAD
$38.97
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
MICROOPTO, Supply module, Screw connection
Documentation & Downloads
Specifications
General Data
| Rail | TS 35 |
|---|---|
| UL 94 flammability rating | V-0 |
| Colour | black |
|---|
Load Side
| Load category | LC A |
|---|
Approvals
| Approvals | CE, EAC |
|---|
Dimensions And Weights
| Width | 6.1 mm |
|---|---|
| Height | 88.1 mm |
| Depth | 97.8 mm |
| Net weight | 32 g |
| Width (inches) | 0.24 inch |
|---|---|
| Height (inches) | 3.468 inch |
| Depth (inches) | 3.85 inch |
Connection Data
| Wire connection method | Screw connection |
|---|---|
| Tightening torque, min. | 0.4 Nm |
| Clamping range, rated connection | 2.5 mm² |
| Clamping range, max. | 4 mm² |
| Wire cross-section, solid, max. | 4 mm² |
| Wire connection cross section, finely stranded, max. | 2.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max. | 1.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), max. | 1.5 mm² |
| Stripping length, rated connection | 7 mm |
|---|---|
| Tightening torque, max. | 0.6 Nm |
| Clamping range, min. | 0.5 mm² |
| Wire cross-section, solid, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded, min. | 0.5 mm² |
| Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min. | 0.5 mm² |
| Conductor cross-section, flexible, AEH (DIN 46228-1), min. | 0.5 mm² |
| Blade size | 0.6 x 3.5 mm |
Classifications
| ETIM 6.0 | EC002586 |
|---|---|
| eClass 9.1 | 27-37-16-92 |
| UNSPSC | 30-21-18-01 |
| ETIM 7.0 | EC002586 |
|---|---|
| eClass 10.0 | 27-37-16-92 |
Environmental Product Compliance
| REACH SVHC | Lead 7439-92-1 |
|---|
Insulation Coordination
| Rated voltage | 300 V |
|---|---|
| Surge voltage category | III |
| Impulse withstand voltage | 4 kV (1.2/50 µs) |
| Pollution severity | 2 |
|---|---|
| Clearance and creepage distances for control side - load side | > 3 mm |
| Protection degree | IP20 |
Temperatures
| Humidity | 5 - 93% rel. humidity, Tu = 40°C, no condensation |
|---|---|
| Operating temperature, min. | -25 °C |
| Storage temperature, min. | -40 °C |
| Storage temperature | -40 °C...80 °C |
| Operating temperature, max. | 60 °C |
|---|---|
| Storage temperature, max. | 80 °C |
| Operating temperature | -25 °C...60 °C |
Further Details Of Approvals / Standards
| Standards | DIN EN 50178, GL 2003-Vl-Abs. 9, IEC 62314, UL508 |
|---|
