Mersen MPDB68323 Power Distribution Block, 1000V, 620A, 3-Pole, Wire Range 350-#6 to 4/0-#10
Mersen MPDB68323 Power Distribution Block, 1000V, 620A, 3-Pole, Wire Range 350-#6 to 4/0-#10
- MPN: MPDB68323
- UPC: 782001453305
- PPN: FER-MPDB68323
Spec sheet
Loading compare button...
In Stock
Company Stock:
00
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Looking to buy a large quantity?
To view product inventory
CAD$999.53/ EA
Description
The Next Generation Power Distribution Block (PDB). Mersen power distribution blocks provide a safe and easy method of splicing cables, splitting primary power into secondary circuits and fulfilling requirements for fixed junction tap-off points. All blocks are UL and CSA approved while meeting spacing requirements for feeder and branch circuits in conjunction with UL508A and the National Electrical Code®. PDB options include single or dual conductor primary inputs and up to 30 secondary outputs. Specialty blocks are available allowing for up to 7 primary inputs. The MPDB series is offered in three size categories: miniature (MPDB62 and MPDB63 series), intermediate (MPDB66 and MPDB67 series), and large (MPDB68 and MPDB69 series), in both aluminum and copper.
Specifications
Specifications
- Rated voltage AC UL
- 1000 V
- Frequency (Hz)
- 50/60 Hz
- ROHS Compliant
- Yes
- Short Circuit Rating (Class CC)
- Not Tested
- Short Circuit Rating (Class J)
- Not Tested
- Short Circuit Rating (Class RK1)
- Not Tested
- Short Circuit Rating (Standalone)
- 10 kA
- Number of Poles
- 3-Pole
- Number of Openings per Pole (Primary)
- 2
- Connector Type (Primary)
- Box
- Hex/Screw Size & Type (Primary)
- 11/16-16 x .88
- Hole Diameter (Primary)
- 0.75 in
- Torque Rating (Primary)
- 350-#6 275
- Wire Range (Primary)
- 350-#6
- Installation Mounting
- Direct Screw Mount
- Width
- 7.89 in
- Height
- 3.55 in
Rated voltage DC UL1000 V
Ampere Rating (CU)620 A
AC or DCAC/DC
Short Circuit Rating (Class G)Not Tested
Short Circuit Rating (Class L)Not Tested
Short Circuit Rating (Class RK5)Not Tested
Short Circuit Rating (Class T)Not Tested
Connector MaterialTin-plated Copper
Number of Openings per Pole (Secondary)4
Connector Type (Secondary)Box
Hex/Screw Size & Type (Secondary)1/2-20 x .75
Hole Diameter (Secondary)0.56 in
Torque Rating (Secondary)4/0-#10 150
Wire Range (Secondary)4/0-#10
Body/Insulating MaterialGlass Filled Polycarbonate
Length5.7 in
Weight10.6 lb
