Schneider Electric M9A26478 Multi9 MX Shunt Trip Release 12/24 V AC/DC, 18 mm Wide, DIN Rail Mount
- MPN: M9A26478
- PPN: SCH-M9A26478
CAD
$49.68
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
This Multi9 MX electrical auxiliary is a shunt trip release. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9mm pitches is 2. The Uc control circuit voltage is 12VAC to 24VAC, or 12VDC to 24VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.
Documentation & Downloads
Specifications
Key Specifications
- [Uc] Control Circuit Voltage
- 12...24 V AC 50/60 Hz || 12...24 V DC
- Product Or Component Type
- shunt trip release
- Device Short Name
- MX
9 Mm Pitches2
RangeMulti9
Complementary
- Height
- 82.5 mm
- Range Compatibility
- Multi 9 Multi9 C60 C60BP || Multi 9 Multi9 C60 C60BPR || Multi 9 Multi9 C60 C60SP || Multi 9 Multi9 GFP GFP || Multi 9 Multi9 C60H-DC C60H-DC
- Net Weight
- 0.06 kg
- Connections - Terminals
- clamp terminal bottom) - 1 2.5-2.5 mm² AWG 14) - rigid || clamp terminal bottom) - 2 1.5-1.5 mm² AWG 16) - rigid
- Local Signalling
- action indicator
- Depth
- 68 mm
Mounting SupportDIN rail
Comb Busbar And Distribution Block Compatibilitytop YES
Wire Stripping Length9 mm for bottom connection
Mounting Modefixed
Width18 mm
Tightening Torque1-1 N.m bottom
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP1305024
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- Circularity Profile
- N/A
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
Reach RegulationFree of Substances of Very High Concern above the threshold
China Rohs RegulationPro-active China RoHS declaration (out of China RoHS legal scope)
Eu Rohs DirectiveCompliant
Environment
- Product Certifications
- UR || PCT || UL
- Standards
- EN/IEC 60947-1 || EN/IEC 60947-5-1 || UL 489 || UL 1077 || C22.2 No. 5 || GB/T 14048.5
- Pollution Degree
- 3
- Relative Humidity
- 95-95 % 55-55 °C
Ambient Air Temperature For Operation-25-50 °C
Tropicalisation2 EN/IEC 60947-1
Ambient Air Temperature For Storage-40-85 °C
