Tripp Lite B072-008-1-IP 8-Port Cat5 KVM Switch with Remote Access, 1U Rack-Mount, Supports VGA 1920x1080
- MPN: B072-008-1-IP
- UPC: 037332183446
- PPN: TRP-B072-008-1-IP
CAD
$1911.44
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Control up to 8 computers from virtually anywhere with one Cat5 KVM switch. This IP KVM switch with remote access is a smart solution for efficient server control. Low-cost Cat5 cables let you locate servers up to 100 ft. away.
Features
- 8-port KVM switch provides control of computers/servers locally or via your network or the Internet
- Occupies just 1U of rack space
- Low-cost Cat5 cabling allows longer distances, reduces cable clutter
- Simultaneous support for 2 users – 1 local, 1 remote
- Dual Ethernet ports assure uninterrupted remote access
- 3-year limited warranty
Documentation & Downloads
Specifications
Additional
- Number of Users
- 2 (1 local, 1 remote)
- Virtual Media Transfer Rate
- Up to 12 Mbps (using B078-101-USB2)
- Input Current
- 120V (1.2A) / 230V (0.7A)
- Power Consumption
- 50 Watts
- Network Speed
- 10/100 Mbps
- Storage Temperature Range
- -40 to 158 F (-40 to 70 C)
- Ports
- 8 (8) RJ45 (FEMALE)
- Rack Space
- 1U
- PS/2 and USB Computer Keyboard and Mouse Interface
- PS/2; USB; USB keyboard/mouse
- Console Interface
- USB keyboard/mouse, VGA monitor
- Shipping Dimensions (H x W x D)
- 4.3 x 10.3 x 22.9 in
- Shipping Weight
- 6.5 lbs (2.95 kg)
- Recommended Category Cable
- Cat5e, Cat6, Cat6a Cables
- Material
- SECC Steel (Steel, Electrogalvanized, Cold rolled, Coil)
- Authentication Supported
- RADIUS; LDAPS (LDAP/S)
- Firmware
- Flash-upgradable over network
- NIAP-Certified Secure
- No
- Approvals
- UL 60950-1, CSA, FCC Part 15 Class A, CE IEC 60950-1, RoHS, REACH
Max Supported Video ResolutionLocal: 1920 x 1200 @ 60 Hz; Remote: 1920 x 1080 @ 60 Hz
Input Voltage Compatibility100-240 VAC (100; 110; 120; 127; 200; 208; 220; 230; 240)
Input Frequency50/60 Hz
BTU Output171 BTU/Hr
Operating Temperature Range32 to 104 F (0 to 40 C)
Relative Humidity0% to 80% RH, Non-Condensing
Port SelectionHotkey; OSD; Remote Selector
Number of Serial Ports2 (for IP PDUs, firewalls, routers control)
Computer Monitor InterfaceVGA
Unit Dimensions (H x W x D)1.7 x 6.7 x 17.3 in
Unit Weight4.6 lbs (2.09 kg)
USB SpecificationUSB 2.0 (up to 480 Mbps)
RackmountableYes
ColorBlack
Security ProtocolTLS 1.2
IP Remote AccessYes
Driver RequiredNo
Product Warranty Period3-year limited
