Burndy YA2CN45 Long Barrel Compression Terminal, 2 AWG, 1 Hole, 35 kV, 600V, Tin Plated
- MPN: YA2CN45
- UPC: 781810313886
- PPN: BUR-10015251
CAD
$29.35
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
Cu Tubing Cu Hylug; 1 Hole w/o Inspection Window; #2 AWG Code,50 Navy; 600V-35kV; 1/2" stud; Long; Compression; 0.56 in BCD; Brown
Documentation & Downloads
Specifications
Dimensions
- Dimension - B Length inch
- 1.25 in
- Dimension - Bolt Size fraction
- 1/2
- Dimension - Height inch
- 1.46 in
- Dimension - Hole Size mm
- 14 mm
- Dimension - Length Overall inch
- 2.70 in
- Dimension - Outside Diameter inch
- 0.42 in
- Dimension - Strip Length inch
- 1-5/16
- Physical Attribute - Tongue Angle
- 45 Degree
Dimension - Bolt Hole Size inch0.52 in
Dimension - D inch1.27 in
Dimension - Hole Size inch0.56 in
Dimension - L Length Overall mm69 mm
Dimension - N inch0.63 in
Dimension - Pad Width inch0.83 in
Dimension - Z inch0.64 in
Certifications and Compliance
- Certification - CSA Approved
- Yes
- Certification - UL Recognized
- No
- Standards - RoHS Compliance Status
- CM
Certification - ETLNo
Certification - cULusNo
UL ListedYes
Conductor Related
- Conductor - Copper Str Navy Size
- 50 (19) Navy
- Conductor - Copper Str Size
- 2 AWG
Conductor - Copper Str Navy Size Range50 (19) Navy
Conductor - MaterialCopper
General
- Color Code
- Brown
- Die Index
- 10
- Feature - Barrel Type
- Long
- Physical Attribute - Number of Holes
- 1
- Plating Type
- Tin - Electro Plated
- Trade Name
- HYLUG™
- UPC
- 781810313886
Connector TypeTerminal
Feature - Barrel StyleChamfered
MaterialCopper
PlatedY
Temperature Rating194
TypeLong Barrel, Tin Plated
UPC 12 Digit7818103138866
Electrical Ratings
- Rating - KVA
- 35 kV
- Voltage - Maximum
- 35000
Rating - Minimum Voltage600
Logistics
- Minimum Pack Quantity
- 5
