Telemecanique Sensors ZCKE636 Limit switch head, Limit switches XC Standard, ZCKE, side metal plunger, -40 °C

The ZCKE limit switch head is a part of the OsiSense XC product range of limit switches. It has a plunger head with a side plunger spring return and linear movement of the operating head. The head is compatible with XCKJ and has multiple associated limit switch bodies. The spring return metal side plunger supports the lateral approach in 1 direction. It weighs 0.2kg. It is suitable for the specific applications such as hoisting, mining, minerals and metals or belt conveying. It is compatible with the XCKJ limit switches. It is associated with ZCKJD37H29, ZCKJ8, ZCKJ5, ZCKJ6H29, ZCKJD37, ZCKJD35H29, ZCKJD31H7, ZCKJD39H29 and ZCKJ11H29 bodies. Limit switches for contact sensing of inflexible objects. An offer of positive opening snap action contacts for a simpler and safer machine design. IEC standard format limit switches consist of products designed according to EN 50047, EN 50041 as well as popular XCM and XCKM limit switches ranges.
