Square D 9001SKT38LYA9 Push-to-Test Pilot Light, 30 mm Amber Domed LED, 120V
- MPN: 9001SKT38LYA9
- UPC: 785901613428
- PPN: SCH-9001SKT38LYA9
CAD
$252.63
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The 30 mm Amber Domed LED Push-to-Test Pilot Light from Schneider Electric is an essential component for automation and control systems, offering a reliable visual indication for equipment status. Designed specifically for ease of integration, this pilot light operates at 120V and features a user-friendly push-to-test function, allowing for quick verification of its operational status. Its durable construction ensures longevity, making it suitable for various industrial applications where dependable performance is critical. With its vibrant amber hue, this pilot light not only enhances visibility but also contributes to efficient monitoring in any control environment.
Documentation & Downloads
Specifications
Additional
- Voltage
- 120 V AC/DC
- Thermal Current
- 10 A
- Impulse Withstand Voltage
- 2.5 kV EN/IEC 60947-1
- Size
- 30 mm
- Dimensions (W x H x D)
- 54 mm x 70 mm x 42 mm
- Bulb Base
- BA 9s
- Shape Of Screw Head
- cross slotted
- Lens Type
- Domed plastic
- Light Source
- Yellow LED
- Tightening Torque
- 0.8 N.m EN/IEC 60947-1
- Protective Treatment
- TC
- NEMA Degree of Protection
- NEMA 1, 2, 3, 3R, 4, 4X, 12, 13
- Shock Resistance
- 50 gn IEC 60068-2-27
- Ambient Temperature Range (Storage)
- -40 to 70 °C
- Mercury Free
- Yes
- Reach Free Of Svhc
- Yes
- REACH
- REACH compliant
- Country of Origin
- Mexico
Rated Insulation Voltage250 V EN/IEC 60947-1
Short-Circuit Protection10 A cartridge fuse EN/IEC 60947-5-1
Operating ModePush-to-test
Mounting Diameter30 mm
Net Weight0.181 kg
Shape Of Signaling Unit Headround
MaterialPolycarbonate lens, plastic bezel
ColorAmber
Contacts Type and Composition1 C/O
Electrical Shock Protection ClassClass II IEC 61140
IP Degree of ProtectionIP66 IEC 60529
Vibration Resistance7 gn (2-500 Hz) IEC 60068-2-6
Ambient Temperature Range (Operation)-25 to 70 °C
StandardsEN/IEC 60947-5-1, UL 508, EN/IEC 60947-5-4, JIS C 852, JIS C8201-5-1, EN/IEC 60947-1, CSA C22.2 No 14, JIS C8201-1
Toxic Heavy Metal FreeYes
RoHSRoHS compliant
China RoHSChina RoHS compliant
