APC AP8659NA3 Rack PDU Metered Outlet Switch, 20A, 208V, 72 Inch Height, 14.93 lb
- MPN: AP8659NA3
- UPC: 731304299523
- PPN: APC-AP8659NA3
CAD
$3149.25
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
APC Metered by Outlet with Switching Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and individual outlet power metering Remote outlet level controls allow power on/off functionality for power recycling to reboot locked-up equipment and to avoid unauthorized use of individual outlets Power sequencing delays allow users to define the order in which to power up or down attached equipment Avoid circuit overload during power recovery and extend uptime of critical equipment by prioritizing the load shedding Current metering provides real-time remote monitoring of connected loads Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles User-defined alarms warn of potential circuit overloads before critical IT failures occur Users can access, configure, and control Switched rack PDUs through secure Web, SNMP, or Telnet Interfaces and is complimented by APC Centralized Management platforms using InfraStruxure Central, Capacity Manager and Change Manager
Features
- Individual outlet level power metering provides a more granular view of the power distributed to equipment within the enclosure. It also provides the ability to analyze component power trends and perform capacity planning.
- Ideal for Colocation, large data centers or distributed IT sites
- Plan capacity and balance loads with +/- 3% metering accuracy (amps, volts, kW, kWh)
- Real-time remote monitoring of connected load through EcoStruxure IT and other platforms
- Stay on top by defining alarm thresholds in order to avoid overloaded circuits
- Zero U toolless installation
- Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles
- User-defined alarms warn of potential circuit overloads before critical IT failures occur
Documentation & Downloads
Specifications
Additional
| Input Voltage | 200 V, 208 V, 230 V |
|---|---|
| Amperage | 20 A |
| Input Frequency | 50/60 Hz |
| Width | 2.20 in (5.6 cm) |
| Weight | 14.93 lb (6.77 kg) |
| Mounting Position | side, vertical |
| Mercury Free | Yes |
| WEEE | N/A |
| Reach Free Of SVHC | Yes |
| Approvals | UL Listed, VCCI Class A, VDE |
| Nominal Output Voltage | 208 V |
|---|---|
| Load Capacity | 3300 VA |
| Height | 72.01 in (182.9 cm) |
| Depth | 2.01 in (5.1 cm) |
| Cord Length | 9.84 ft (3.00 m) |
| Input Connection Type | NEMA L6-20P |
| Lead Free | Yes |
| RoHS | Compliant with Exemptions |
| Reach | Free of SVHC above threshold |
| Warranty | 24 months |
