APC AP7869B Rack PDU Metered Zero U 14.4kW 208V (24)C13 (4)C19 (2)L6-30R

MPN: AP7869B
UPC: 731304331544
PPN: APC-AP7869B

$3179.10

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

It is a metered rack PDU designed for Zero U vertical mounting. It supports a maximum current of 40A and operates at 208V. The PDU features 24 IEC 60320 C13, 4 IEC 60320 C19, and 2 NEMA L6-30R outlets. It has a load capacity of 14400 VA and includes a cord retention bracket, installation guide, and rack mounting brackets.

Features

Enables a quick recovery from overload events.
Server cases do not require additional tools to mount into NetShelter Enclosures, which allows the users to quickly and easily mount units in the rear of the enclosure.
Easily mounts vertically in racks or enclosures and occupies zero U of valuable rack space, which allows more equipment in the rack. Units that mount vertically are optimized to fit in a NetShelter enclosures.
Provides 24 IEC 60320 C13, 4 IEC 60320 C19, and 2 NEMA L6-30R outlets for comprehensive power distribution
Vertical mounting to save valuable rack space
Supports up to 40A, 208V power distribution, ensuring reliable power delivery
Includes a cord retention bracket and toolless mounting kit for quick setup

Documentation & Downloads

Specifications

Additional

Output Voltage	208 V
Height	70 in (177.8 cm)
Depth	3.74 in (9.5 cm)
Mounting Position	side, vertical
Cord Length	3 ft (0.91 m)
RoHS	Compliant with Exemptions
Lead Free	Yes

Input Voltage	208 V 3 phase
Weight	22.84 lb (10.36 kg)
Width	2.2 in (5.6 cm)
Rack Height	0U
Approvals	cUL Listed, CSA, Industry Canada, METI Denan, UL Listed
REACH	Free of SVHC above threshold
Mercury Free	Yes
