Hubbell Premise Wiring CFB4G25CRE 4-Gang Recessed Concrete Floorbox, 14.57" x 11.20" x 2.50" Depth

MPN: CFB4G25CRE
UPC: 783585695266
PPN: HBL-CFB4G25CRE
UNSPSC: 39121307

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$572.85/ EA

Loading add to cart quantity...

Description

SystemOne ETERNAL™ Series Concrete Floorboxes, Galvanized Stamped Steel Box, Recessed, 4-Gang CFB E-Series Box for Rectangular Covers, 2.50" Minimum Depth of Pour, Corrosion Resistant Paint

Features

Corrosion-Resistant Painted Recessed 4-Gang Rectangular Cover Floorbox
For Use In Concrete Floors
3.75" Deep Wiring Chambers
Box Includes Installation Cover & 1/2" Prepour Cap
2.50" Minimum Depth of Pour
Each Gang Includes (1) 6" Solid #12 AWG Conductor Grounding Pigtail
Pregalvanzied Stamped Steel Box with Corrosion Resistant Paint; Concentric Knock-Outs;High-Capacity Feed-Through (External Hubs Purchased Separately)

Specifications

Dimensions: 14.57 in x 11.20 in x 2.50 in

Finish: Green corrosion resistant epoxy paint

Mounting Method: Screw Mount Device Mounting Plates

Application: For Use in Concrete Floors

Wiring Chamber Depth: 3.75 in

Device Chamber Grounding: 6 in #12 AWG solid copper wire

Buy American Compliant: Yes

Style: 4-Gang

MaterialGalvanized Stamped Steel, 16 gauge

Mounting TypeField Installed

TypeRecessed

Trade Size Knock-Outs(4) 1/2", 3/4", 1"

Wiring Chamber Volume166 in³

CompliancecULus Listed, UL 514A Listed

ColorMetallic/Green Epoxy Paint

Number of Gangs4-Gang
