Eaton TWR270GY Eaton residential grade duplex rece — Features: Tamper resistant Weather resistant, Allowable Wire Size: Push-In Terminals Wiring: #14 AWG copper (CU) Only, Side Wiring: #10-14 Copper or Copper Clad Aluminum, Color: Gray, Face/Body Material: Impact-resistant thermoplastic, Style Type: Standard, NEMA Configuration: 5-15R, Packaging Type: Core pack

MPN: TWR270GY
UPC: 032664745201
PPN: COW-TWR270GY

$3.87

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

Eaton residential grade duplex receptacle, #14-10 AWG, 15A, Commercial, Residential, Flush, 125V, Side and push, Gray, Brass, Weather resistant, Impact-resistant thermoplastic, 5-15R, Duplex, Screw, Thermoplastic, Core pack

Specifications

Key Specifications

Length	1.31 in
Width	0.69 in
Nom Product Type	Residential grade
Type	Duplex receptacle
Voltage Rating	125V
Application	Commercial/residential
Wiring Method	Side and push
Number Of Wires	3
Number Of Poles	Two-pole
Material	Thermoplastic
Color	Gray
Allowable Wire Size	Push-In Terminals Wiring: #14 AWG copper (CU) Only, Side Wiring: #10-14 Copper or Copper Clad Aluminum
Torque Rating	14 lbf-inch
Face/Body Material	Impact-resistant thermoplastic
Product Series	Straightblade Receptacles

Height	4.19 in
Weight	0.01 lbs
Device Type	Receptacle
Amperage Rating	15A
Contact Material	Brass
Device Grade	Standard grade
Environmental Conditions	Damp/wet
Mounting Method	Flush
Style Type	Standard
Environmental Resistance	Weather resistant
Connection Type	Screw
NEMA Configuration	5-15R
Design Type	Straight blade
Receptacle Type	Duplex
