Schneider Electric NSYTRV42STAR Linergy TR Terminal Block, 2 Points, 4 mm², Orange
- MPN: NSYTRV42STAR
- PPN: SCH-NSYTRV42STAR
CAD
$15.78
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Linergy TR Terminal Block from Schneider Electric serves as a vital component in automation and control systems, designed to ensure efficient connectivity and reliable electrical performance. Featuring two connection points with a 4 mm² capacity, this terminal block not only enhances circuit management but also simplifies installation due to its user-friendly design. Its distinctive orange color aids in easy identification, making it an ideal choice for professionals seeking both functionality and clarity in their electrical setups.
Documentation & Downloads
Specifications
Additional
- Rated Current
- 20 A EN/IEC 60947-7-1, 16 A CSA, 16 A cURus
- Number of Connection Points
- 2
- Width
- 0.24 in (6.2 mm)
- Connection Type
- 1 x screw terminal upstream, 1 x screw terminal downstream
- Mounting Mode
- Clip-on
- Dielectric Loss
- 0.01 at 1 MHz
- Resistivity
- 10000 MΩ·m
- Creep Resistance
- 500 CTI (> 400 kB)
- Dielectric Strength
- 1000 V IEC 60243-1
- Compliance
- CSA, cURus, EAC, RoHS Compliant with Exemptions
- Country of Origin
- Germany
- Product Name
- Linergy TR
Rated Operational Voltage500 V EN/IEC 60947-7-1, 600 V CSA, 600 V cURus
Length2.28 in (57.8 mm)
Height1.93 in (49.1 mm)
Connection PositionSideways
MaterialPolyamide 6/6 insulating case
Dielectric Constant3.7 at 1 MHz
Surface Resistance1000 GΩ
Flame RetardanceV0 0.8 mm UL 94
Ambient Air Temperature Range-40 to 130 °C (-40 to 266 °F)
Halogen ContentHalogen free plastic parts
Device Short NameTRV
