Pass & Seymour 420I Specification Grade Quad Receptacle 20A 125V, 4.5 Inch Width, Ivory Color
- MPN: 420I
- UPC: 785007496376
- PPN: P-S-420I
CAD
$79.16
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
Specification Grade Quad Receptacle 20A 125V, 4.5 Inch Width, Ivory Color
Features
- Rugged nylon face and body withstands impacts and hard use.
- Built-in wire stripping gauge.
- Outward-facing ground terminals make handling up to four straight or angled plugs easy and convenient.
- Heavy-duty, phosphor bronze contacts.
- Shielding walls guard against live-circuit-to-ground shorts.
- Split circuit break-off tabs.
- UL and CSA listed.
- For covering patents, see www.legrand.us/patents.
- For compatible wall plate options, from our TradeMaster unbreakable plates to our radiant screwless plates to our metal wall plates, click here.
Documentation & Downloads
Specifications
Key Specifications
- Width
- 4.5 in
- Country of Origin
- Mexico
- Standard
- UL498
- Voltage
- 125.0 V
- Number of Wires
- 3.0
- Wire Size
- 14 - 12 AWG
- Features
- Impact Resistant
- Standard
- CSA C22.2 No. 42
- Number of Poles
- Double Pole
- NEMA Configuration Code
- 5-20R
- Wire Connection Type
- Screw Terminals
- Environmental Conditions
- Flammability: UL94 V2 and UL94-5 VA
ColorIvory
Product LinePass & Seymour
Amperage20.0 A
Mounting TypeBox
Indoor/OutdoorIndoor
Wall Plate IncludedNo
Number of Receptacles4.0
Outlet TypeStraight Blade
Application SectorCommercial
Connection LocationBack and Side
Warranty Type1-Year Limited Warranty
Special FeaturesRugged nylon face and body withstands impacts and hard use. Built-in wire stripping gauge. Outward-facing ground terminals make handling up to four straight or angled plugs easy and convenient. Heavy-duty, phosphor bronze contacts. Shielding walls guard against live-circuit-to-ground shorts. Split circuit break-off tabs.
