Bryant

Bryant 60302D Industrial Grade Toggle Switch, 60A 600V AC, Double Pole, NEMA 3R Enclosure

Industrial Grade Toggle Switch, 60A 600V AC, Double Pole, NEMA 3R Enclosure
  • MPN: 60302D
  • UPC: 781786631779
  • PPN: HBL-60302D
  • UNSPSC: 39121521

Spec sheet

Loading compare button...

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$453.54/ EA

Description

Switches and Lighting Controls, Industrial Grade, Toggle Switches, Manual Motor Controllers, Double Pole, 60A 600V AC, Side Wired Only, Black, With NEMA 3R Enclosure

Features

  • Toggle
  • Manual Motor Controllers
  • Double Pole
  • 60A 600V AC
  • Side Wired Only
  • Back Wired

Specifications

Specifications

Number of Poles
2 Pole
General Literature Asset 1 Display Text
General Literature - Motor Controllers and Disconnects
Current / Amperage Rating
60 A
Standards - RoHS Compliance Status
CM
Voltage Rating Description
600V AC kV
Application
Red Slide
Display Size
Standard Sized Product
Environmental Conditions
Indoor and Outdoor
Number Of Poles
2 Pole
Operating Temperature
Minimum Continuous -40 Deg C without Impact
Style
Standard Duty
Wattage
36000
Description - Invoice
60A 600V 2P DISC SW W/NEMA 3R
Harmonization Code
8536509901
MSDS Flag
No
Sub Class Code
A16A240
Current Rating
60 A
Base Unit of Measure
EA
Carton - Gross Weight per Pack
4.800 lb.
Carton - Pack Description
Carton
Carton - Total Units
4 EA
Lowest Level UOM
Each
Special FeaturesBack Wired
Country of OriginUnited States
Width4.810 in
Voltage Rating600V AC kV
Amperage Rating60 A
ConnectivityPressure Terminal Screws
Enclosure TypeNEMA 3R
Load CapacityInductive
Operating Cycles10,000 Cycles Minimum
PhaseSingle Phase
TypeDisconnect Switches
Class CodeA16
Freight Class Code06168002
Image Actual Or RepresentativeA
Replaced Catalog Number60302
Material - Mounting HardwareScrew Mounting
SeriesNon-Fused
BOX SIZE11.300x12.300x10.000 (in)
Carton - Number of Sub Packs4
Carton - SCC-14 Next Lower Level Sub Pack781786631779
Each - Pack DescriptionEach

Certifications

EU RoHS Indicator
No
