Schneider Electric NSYMD128 Symmetrical Mounting Chassis 7 Rails for H1200xW800mm Enclosure
- MPN: NSYMD128
- PPN: SCH-NSYMD128
CAD
$400.94
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
Engineered for optimal integration within enclosures, the Symmetrical Mounting Chassis from Schneider Electric is tailored for the H1200xW800mm model, featuring seven rails designed to provide robust support for various components. This essential accessory facilitates effective organization and efficient utilization of space, ensuring that critical systems are securely mounted and easily accessible. By combining reliable design with functionality, it enhances the overall effectiveness of automation and control applications, making it a valuable addition to any data and communication setup.
Documentation & Downloads
Specifications
Additional
- Type Of Rail
- Symmetrical DIN
- Height
- real 1152.4 mm, nominal 1200 mm
- Depth
- real 30 mm
- Mounting Support
- spacer, direct fixing on backstuds, step slide
- Device Application
- multi-purpose
- Range Compatibility
- Spacial Spacial CRN, Spacial Spacial S3D, Spacial Spacial S3X, Thalassa Thalassa PLM
- Product Or Component Type
- chassis
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
- Mercury Free
- Yes
- Reach Regulation
- Free of SVHC above threshold
- Sustainable Offer Status
- Green Premium product
- Circularity Profile
- N/A
Adjustment Pitch12.5 mm
Widthnominal 800 mm, real 750 mm
Materialuprights aluminium, rail steel
Device Composition2 uprights, 7 DIN rails, fixing elements
RangeSpacial
Fixing Modescrewed on backstuds, by fixing element
Rohs Exemption InformationYes
Toxic Heavy Metal FreeYes
Environmental DisclosureENVPEP100104EN
China Rohs RegulationPro-active China RoHS declaration (out of China RoHS legal scope)
Warranty18 months
Country of OriginFrance
