Schneider Electric LAD4DDL TeSys U-Line Flywheel Diode Suppressor Module for 5-600V DC

MPN: LAD4DDL
PPN: SCH-LAD4DDL

$53.97

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys Deca suppressor module, for contactors LC1D09-D38, LC1DT20-DT40 and control relays CAD. To be used with 5-600V DC control circuit voltage, it provides a flywheel diode protection ensuring no transient overvoltage. Clip-on side mounting, overall size of the contactor is unchanged.

Features

Engineered with high-efficiency flywheel diode technology, the LAD4DDL safely suppresses the massive transient counter-EMF spikes generated when a contactor coil is de-energized. By strictly limiting peak voltage to 1 U_c, it safeguards nearby solid-state automation equipment, PLCs, and digital I/O modules from electrical noise interference or terminal breakdow
Boasting an ultra-wide operational footprint from 5V to 600V DC, this versatile suppressor module seamlessly integrates with standard 12V, 24V, 48V, or high-voltage DC control circuits. This broad compatibility eliminates the need to source and stock multiple voltage-specific surge arresters, drastically simplifying your control panel bill of materials (BOM)
This module is purpose-built for a perfect mechanical fit with Schneider Electric 3-pole LC1D09 to LC1D38 contactors, 4-pole LC1DT20 to LC1DT40 contactors, and CAD32/CAD50 control relays. This targeted architectural integration prevents mechanical misfits and ensures robust, reliable terminal alignment across your entire motor control lineup.
Designed with an innovative, snap-on clip mechanism, the module mounts securely to the side of the contactor without requiring screws or specialized tools. This rapid interface architecture reduces field wiring labor costs while keeping the overall front footprint of your TeSys Deca device completely unchanged, optimizing high-density DIN rail spacing.
Fully certified to UL 60947-5-1, CSA C22.2, IEC 60947-5-1, and CE standards, this suppressor module meets the strict safety benchmarks required for heavy industrial deployment. Incorporating an IP2X touch-safe housing, it guarantees reliable risk mitigation against accidental finger contact while keeping your automation panels completely

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	Brazil, France, United Kingdom, United States

Complementary Attributes

Maximum Peak Voltage	1 Uc

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SI
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Range Of Product	TeSys Deca, TeSys Deca control relay
Carbon Footprint Of The Distribution Phase [A4]	0.0014524, 0 kg CO2 eq.
Carbon Footprint Of The Manufacturing Phase [A1 To A3]	0.1 kg CO2 eq., 0.11049
Local Data Status	Publishable
Return Indicator	Y
Stock Policy	2
Traceability	No
Weee Scope	In
Scope Perimeter	At least in Europe
Reach Full Compliance Status	Reference contains Substances of Very High Concern above the threshold
Reach Compliance Directive	Reference contains Substances of Very High Concern above the threshold
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	No
Tier Id	1
Function Option Id	STANDARD
Product Kit Identifier	N
Device Short Name	LAD4
Mounting Mode	by clips
Product Or Component Type	suppressor module
Returnability	Yes
Suppressor Technology	flywheel diode
Total Lifecycle Carbon Footprint	0.1 kg CO2 eq.
Pep Code	ENVPEP1112053EN
Pep Verification Date	2025-11-10
Psr Version	PSR-0005-ed2-2016 03 29
Data Source	referent product
Functional-unit Quantity	1
Reference Lifetime In Y	20
Energy Model - Installation [A5]	Electricity Mix; Production mix; Low voltage; FR
Energy Model - End Of Life [C1-c4]	Electricity Mix; Production mix; Low voltage; FR
[Uc] Control Circuit Voltage	5...600 V DC
Package Weight(Lbs)	5.200 g
Warranty (In Months)	18
Ecotoxicity (Fresh Water) (Ctue) Manufacturing [A1-a3]	48.858
Total Use Of Primary Energy During The Life Cycle (Mj) Manufacturing [A1-a3]	1.8918
Water Use (M3 Eq) Manufacturing [A1-a3]	0.0364

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, System Integrator
Market Segmentation	Commercial, Industrial
Certificate Agency	UL, CSA
Carbon Footprint Of The End-of-life Phase [C1 To C4]	0 kg CO2 eq., 0.036757
Carbon Footprint Of The Use Phase [B2 B3 B4 B6]	kg CO2 eq., 0
Local Publishable Date	2026-07-07
Stocking Flag	N
Serviceability	No
Field Service Division	PPIBS
Weee Product Category	5
Eoli Availability Display	No need of specific recycling operations
Reach Full Compliance Status Id	CONTAINS_SVHC
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	1926
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	1
Function Option	Standard
Compatibility Code	LAD4
Mounting Location	side
Product Availability	Stock - Normally stocked in distribution facility
Range	TeSys
Software Version	v5.9.4
Sustainable Packaging	Yes
Weee Label	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Database Version	2022-01
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
Functional-unit Description	It provides a flywheel diode protection ensuring no transient overvoltage. Clip-on side mounting, overall size of the contactor is unchanged.
Functional-unit Unit	unit
Energy Model - Manufacturing [A1-a3]	Electricity Mix; Production mix; Low voltage; FR
Energy Model - Use [B6]	Electricity Mix; Production mix; Low voltage; FR
Recyclability Potential In %	20
Nbr. Of Units In Pkg.	1
Take-back	No
Depletion Of Abiotic Resources - Fossil Fuels (Mj) Manufacturing [A1-a3]	1.8712
Hazardous Waste Disposed Of (Kg) Manufacturing [A1-a3]	0.23
Use Of Non-renewable Primary Energy Excluding Non-renewable Primary Energy Resources Used As Raw Materials (Mj) Manufacturing [A1-a3]	1.6497
Customs Code	8536308000

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Ambient Air Temperature For Storage	-40-80 °C, -40-80 °C
Take Back	No
Toxic Heavy Metal Free	Yes
Carbon Footprint	0.1486994
Eu Rohs Directive	Compliant
Packaging Made With Recycled Cardboard	Yes
Reach Regulation	Reference contains Substances of Very High Concern above the threshold
Pep Verification Date	2025-11-10
Psr Version	PSR-0005-ed2-2016 03 29

Ambient Air Temperature For Operation	-25-55 °C, -25-55 °C
Product Compatibility	3P LC1D09...D384P LC1DT20...DT40, 4P LC1D098...D258, CAD32, CAD50
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP1112053EN
Ip Degree Of Protection	IP2XIEC 60529
Packaging Without Single Use Plastic	No
Pep Code	ENVPEP1112053EN
Pcr Version	PEP-PCR-ed4-2021 09 06
Type Of Verification For The Pep	Independent internal review
