Bryant RR450FW Straight Blade Single Receptacle 50A 125/250V 3-Pole 4-Wire Flush Mount
- MPN: RR450FW
- UPC: 883778100765
- PPN: HBL-RR450FW
- UNSPSC: 39121406
CAD
$19.12
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Description
tradeSELECT® Straight Blade Residential Grade, Single, 50A 125/250V, 3-Pole 4-Wire Grounding, 14-50R, Flush Mount
Features
- Sequenced contacts assure protection
- Catalog number, ratings and certifications molded in face
- One piece design power and ground contacts
- Flush Mount Receptacle
Documentation & Downloads
Specifications
Key Specifications
- Country of Origin
- China
- Width
- 2.550 in
- Amperage Rating
- 50 A
- Color
- Black
- NEMA Rating
- 14-50R
- Number of Wires
- 4-Wire
- Special Features
- Flush Mount Receptacle
- Type
- Single Receptacle
- Wattage
- 12500
- Voltage Rating Description
- 125/250 V
- Connectivity
- Pressure Terminal Screws
- Nema Rating
- 14-50R
- Number Of Wires
- 4-Wire
- Description - Invoice
- RECPT, SB, 50A 125/250V, 3P4W, FLNG, WH
- Harmonization Code
- 8536698000
- MSDS Flag
- No
- Current Rating
- 50 A
- Base Unit of Measure
- EA
- Carton - Gross Weight per Pack
- 3.65 lb.
- Carton - Pack Description
- Carton
- Carton - Total Units
- 10 EA
- Case Weight
- 8.516 lb.
- Lowest Level UOM
- Each
- Pallet Height
- 45.600 in
- Pallet Weight
- 1103.200 lb.
Current / Amperage Rating50 A
Industry Standard(s)UL Listed
ApplicationResidential Range and Dryer Devices
Environmental ConditionsIndoor Dry Unless Protected By Additional Means
Number of Poles3-Pole
PhaseSingle Phase
StandardUL Listed
Voltage Rating125/250 V
Wire Size#6 AWG
General Literature Asset 1 Display TextResidential Catalog
Display SizeStandard Sized Product
Number Of Poles3-Pole
StyleSmooth Face
Freight Class Code06168002
Image Actual Or RepresentativeA
Material - Mounting HardwareScrew Mounting
SeriesHeavy Duty
BOX SIZE4.000x12.100x5.600 (in)
Carton - Number of Sub Packs10
Carton - SCC-14 Next Lower Level Sub Pack883778100765
Case - Total Units50 EA
Each - Pack DescriptionEach
Pallet - GTIN - Package70883778100764
Pallet Length48.000 in
Pallet Width40.000 in
Certifications
- EU RoHS Indicator
- Yes
