Tripp Lite PDUH20DV 1.6–3.8kW Single-Phase 100–240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with L6-20P Adapter, 12 ft. Cord, 1U Rack-Mount

1.6–3.8kW Single-Phase 100–240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with L6-20P Adapter, 12 ft. Cord, 1U Rack-Mount
1.6–3.8kW Single-Phase 100–240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with L6-20P Adapter, 12 ft. Cord, 1U Rack-Mount
1.6–3.8kW Single-Phase 100–240V Basic PDU, 14 Outlets (12 C13 & 2 C19), C20 with L6-20P Adapter, 12 ft. Cord, 1U Rack-Mount
  • MPN: PDUH20DV
  • UPC: 037332158963
  • PPN: TRP-PDUH20DV

Spec sheet

Available to Order

Company Stock:

0

Lead times may vary. For an accurate estimate please contact us.

Looking to buy a large quantity?

To view product inventory

CAD$372.02/ EA

Description

Versatile 20A 100–240V PDU is compatible with wide range of voltages to deliver single-phase AC power to multiple loads from a utility outlet, generator or UPS system. Ideal for data centers, server rooms and network wiring closets.

Features

  • C20 input with detachable 12 ft. cord and L6-20P adapter
  • 14 total outlets—12 C13 and 2 C19
  • Switchless design prevents accidental shutdown
  • Reversible all-metal housing
  • Installs in rack, on wall or under counter
  • 5-year limited warranty

Specifications

Certifications

Certifications
Tested to UL 60950 (USA), CSA (Canada), CE (EU), RoHS Compliant

Physical

Form Factors Supported
1U rackmount, 0U vertical rackmount, wall-mount, and under-counter installation
Minimum Required Rack Depth (inches)
6.8
PDU Form Factor
Horizontal (1U)
Shipping Weight (lbs.)
5.50
Unit Weight (lbs.)
3.75
Material of ConstructionMetal
Outlets Measurement (Center to Center)Distance between front (C13) outlets = 28.75mm; Distance between rear (C19) outlets = 55mm; Distance between rear (C13) outlets = 28.75mm
Shipping Dimensions (hwd / in.)2.25 x 10.90 x 20.10
Unit Dimensions (hwd / in.)1.75 x 17.25 x 3.75

User Interface, Alerts & Controls

Switches
n/a

Input

PDU Input Voltage
100; 120; 127; 200; 208; 220; 230; 240
Maximum Input Amps
20
PDU Plug Type
NEMA L6-20P; IEC-320 C20
Input Cord Details
Input cable is detachable PDU C20 inlet
Recommended Electrical Service20A 120V; 20A 208/240V; 16A 230V
Maximum Input Amps DetailsAgency de-rated to 16A continuous
Input PhaseSingle-Phase
Input Cord Length (ft.)12

Output

Frequency Compatibility
50 / 60 Hz
Output Receptacles
(12) C13; (2) C19
Overload Protection
n/a
Output Capacity Details3.84kW (240V), 3.68kW (230V), 3.52kW (220V), 3.33kW (208V), 3.2kW (200V), 2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 16A total capacity; 16A max per C19 outlet; 12A (10A CE) max per C13 outlet
Output Nominal Voltage100; 120; 127; 200; 208; 220; 230; 240

Environmental

Storage Temperature Range
-30°C to +50°C (-22°F to +122°F)
Operating Elevation (ft.)
0-10,000
Relative Humidity5 to 95% non-condensing
Operating Elevation (m)0-3000

Overview

UPC Code
037332158963
PDU TypeBasic

Special Features

TVSS Grounding
Rear panel grounding lug

Warranty

Product Warranty Period (Worldwide)
5-year limited warranty
