Telemecanique Sensors XS7C2A1MAU20 Inductive proximity sensors XS, inductive sensor XS7 40x40x70, PBT, Sn15 mm, 24...240VAC/DC, 1/2"
- MPN: XS7C2A1MAU20
- PPN: TES-XS7C2A1MAU20
- UNSPSC: 39122230
CAD
$291.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Inductive proximity sensors XS, inductive sensor XS7 40x40x70, PBT, Sn15 mm, 24...240VAC/DC, 1/2"
Documentation & Downloads
Specifications
Key Specifications
| Electrical Connection | male connector 1/2"20 UNF, 3 pins |
|---|---|
| Discrete Output Function | 1 NO |
| Range Of Product | Telemecanique Inductive proximity sensors XS |
| Material | plastic |
| Wiring Technique | 2-wire |
| Series Name | general purpose |
| [Sn] Nominal Sensing Distance | 15 mm |
| Detector Flush Mounting Acceptance | flush mountable |
| Sensor Design | form 40 x 40 x 70 |
| Output Circuit Type | AC/DC |
| [Us] Rated Supply Voltage | 24...240 V AC 50/60 Hz || 24...240 V DC |
|---|---|
| Type Of Output Signal | discrete |
| Sensor Name | XS7 |
| Size | 70 mm |
| Ip Degree Of Protection | IP67 IEC 60529 || IP65 IEC 60529 || IP69K DIN 40050 |
| Body Type | fixed |
| Sensor Type | inductive proximity sensor |
| Switching Capacity In Ma | 5...200 mA DC || 5...300 mA AC |
| Enclosure Material | PBT |
Complementary
| Height | 40 mm |
|---|---|
| Status Led | supply on 1 LED green) || output state 1 LED yellow) |
| Operating Zone | 0-12 mm |
| Marking | CE |
| Net Weight | 0.149 kg |
| Switching Frequency | <= 25 Hz AC || <= 50 Hz DC |
| Maximum Delay Recovery | 1.8 ms |
| Supply Voltage Limits | 20-264 V AC/DC |
| Width | 70 mm |
| Maximum Delay Response | 1.2 ms |
|---|---|
| Repeat Accuracy | <= 3% of Sr |
| Maximum Voltage Drop | <5.5 V closed) |
| Length | 40 mm |
| Maximum Residual Current | 1.5 mA open state 120 V || 0.6 mA open state 24 V |
| Differential Travel | 3...15% of Sr |
| Maximum Delay First Up | 7.5 ms |
| Detection Face | 5 positions turret head |
| Front Material | PBT |
Environment
| Product Certifications | CSA || CCC || UL |
|---|---|
| Vibration Resistance | 25 gn +/- 2 mm 10-55 Hz)IEC 60068-2-6 |
| Ambient Air Temperature For Storage | -40-85 °C |
| Ambient Air Temperature For Operation | -25-70 °C |
|---|---|
| Shock Resistance | 50 gn 11 msEN 60068-2-27 |
Contractual warranty
| Warranty | 18 months |
|---|
Offer Sustainability
| Rohs Exemption Information | Yes |
|---|---|
| Environmental Disclosure | ENVPEP121217EN |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Mercury Free | Yes |
|---|---|
| Sustainable Offer Status | Green Premium product |
| Eu Rohs Directive | Pro-active compliance (Product out of EU RoHS legal scope) |
