APC SRT2200XLA Smart-UPS On-Line 2200VA Tower 120V 6x 5-20R 1x L5-20R Sine Wave

MPN: SRT2200XLA
UPC: 731304325161
PPN: APC-SRT2200XLA

$3544.78

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 2200VA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with NEMA 5-20P input, 6x NEMA 5-20R and 1x NEMA L5-20R outlets. It has a SmartSlot for optional Network Management Card that enables graceful shutdown of physical servers, virtual machines & HCI Clusters via PowerChute Network Shutdown. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK4 (4-post) and SRTRK3 (2-post) rail kits sold separately.

Features

Text and mimic diagrams that display modes of operation, system parameters and alarms.
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
2200VA/1800W double-conversion on-line pure sine wave tower UPS
Ideal for servers, storage, voice/data networks, medical labs, and light industrial applications
Rack/Tower convertible (rail kit SRTRK4 or SRTRK3 sold separately)
Delivers clean power with zero transfer time for critical or sensitive devices
Add up to 10 external battery packs (SRT72BP) for extended runtime
Graceful shutdown using serial or USB cables via PowerChute Serial Shutdown

Documentation & Downloads

Specifications

Additional

Output Power Capacity	2200 VA
Weight	55.12 lb (25 kg)
Cable Length	6 ft (1.83 m)
Output Connections	6 NEMA 5-20R, 1 NEMA L5-20R
Typical Recharge Time	3 h
Topology	Double Conversion Online
Color	Black
Mounting Position	front, vertical
RoHS	Compliant with Exemptions
California Proposition 65	Prop 65 Compliant

Input Voltage	120 V
Dimensions (H x W x D)	3.35 in x 17.01 in x 22.99 in (85 mm x 432 mm x 584 mm)
Input Connection Type	NEMA 5-20P
Battery Type	Lead-Acid battery
Surge Energy Rating	340 J
Waveform Type	Sine wave
Country of Origin	Philippines
Mercury Free	Yes
Approvals	ENERGY STAR V2.0 (USA)
