APC SMX750I Smart-UPS X 750VA Line Interactive Rack/Tower 2U 230V Sine Wave Output
- MPN: SMX750I
- UPC: 731304268581
- PPN: APC-SMX750I
CAD
$1422.39
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Company Stock:
0
Looking to buy a large quantity?
To view product inventory
Spec sheet
Description
Smart-UPS X 750VA Line Interactive Rack/Tower 2U 230V Sine Wave Output
Features
- Auto recognition of external batteries — UPS recognizes when external battery packs are attached and automatically adjusts runtime.
- Cold-start capable — Provides temporary battery power when the utility power is out.
- Energy meter — Provides actual kilowatt hours of usage for energy conscious users.
- EPO — Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
- Green mode — Patent-pending operating mode that bypasses unused electrical components in good power conditions to achieve very high operating efficiency without sacrificing any protection.
- High frequency design — Reduces or eliminates bulky transformers resulting in lighter units for ease of handling.
- High online efficiency — Reduces utility costs, generates less heat.
- Intelligent Card Slot — Customize UPS capabilities with management cards.
- Intuitive LCD interface — Provides clear and accurate information in multiple languages with the ability to configure the UPS locally with easy to use navigation keys.
- Multiple switched outlet groups — Multiple outlet groups that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- Plug-and-Play external batteries — Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
- Predictive replace battery date — Dynamically provides the month and year when battery replacement is recommended to aide in long term maintenance planning.
- Pure sine wave output on battery — Simulates utility power to provide the highest degree of compatibility for active PFC (power factor corrected) servers and sensitive electronics.
- Rack/Tower convertible — Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
- Scalable runtime — Allows additional run time to be quickly added as needed.
- Single switched outlet group — Single outlet group that may be controlled separately from the UPS for discrete reboot of hung devices, sequenced on/off and non-critical load shedding.
- Temperature-compensated battery charging — Prolongs battery life by regulating the charge voltage according to battery temperature.
Documentation & Downloads
Specifications
Additional
- Power Capacity
- 750 VA / 600 W
- Nominal Input Voltage
- 230 V
- Output Frequency
- 47 - 53 Hz (50 Hz nominal), 57 - 63 Hz (60 Hz nominal)
- Topology
- Line interactive
- Surge Energy Rating
- 645
- Height
- 8.9 cm (3.5 in)
- Depth
- 49.0 cm (19.0 in)
- Input Connection Type
- IEC 320 C14
- Battery Type
- Maintenance-free sealed lead-acid, leak proof
- Interface Ports
- Serial (RJ45), USB, SmartSlot
- RoHS
- Compliant
- Product Orientation
- Rack Using Kit
Input Voltage Range160 - 286 V (150 - 300 V max adjustable)
Output Voltage230 V (configurable to 220 or 240 V)
Waveform TypeSine wave
Output Power Capacity, VA750
Rack Height2U
Width43.2 cm (17.0 in)
Weight23 kg (48.5 lb)
Output Connections(8) IEC320 C13
Typical Recharge Time3 hours
Emergency Power Off (EPO)Yes
ApprovalsCE, EAC, RCM, VDE
ColorBlack
