Federal Pioneer NA3P60 Stab-Lok Circuit Breaker 60A 3 Pole 240 Volt 10 kA Plug-In Mount
- MPN: NA3P60
- UPC: 047569371011
- PPN: SCH-NA3P60
CAD
$473.35
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
Stab-Lok circuit breakers are one, two, and three pole thermal magnetic circuit breakers that provide arc fault circuit interrupters for Federal Pioneer panels. They have easy to read color coded handles to differentiate ampere ratings. This breaker is a three pole 60A, 240VAC moulded case breaker with plug in mounting. This circuit breaker meets CSA standards.
Features
- Purpose-built as a genuine replacement component, this plug-in breaker is engineered specifically to seat firmly into existing Federal Pioneer Stab-Lok residential and commercial panels. This flawless mechanical compatibility allows contractors and facility maintenance technicians to safely repair or upgrade older, established Canadian electrical panels without requiring a full, disruptive, and costly panelboard replacement.
- Delivering a substantial 60-amp continuous current rating at 240V AC across three distinct poles, this heavy-duty breaker provides the robust performance needed to protect high-demand infrastructure. It is ideal for feeding heavy sub-panels, industrial HVAC compressors, commercial kitchen appliances, and three-phase shop machinery, preventing overloads from stalling your primary operations.
- Engineered with a robust 10,000-amp short-circuit breaking capacity, this molded-case circuit breaker provides a vital line of defense against sudden electrical surges. It safely absorbs and extinguishes high-energy electrical arcs before they can warp internal hardware or compromise panelboard enclosures, ensuring full compliance with rigorous CSA standards.
- Equipped with heavy-duty screw connectors, the terminal assembly accepts wire sizes ranging from 14 AWG up to 1/0 AWG copper. This versatile wiring range accommodates thick commercial feeder cables and guarantees a low-resistance, corrosion-stable connection, simplifying routine terminal torque checks during standard panel audits.
Documentation & Downloads
Specifications
Key Specifications
- Range Of Product
- Stab-lok
- [In] Rated Current
- 60 A
- Breaking Capacity
- 10 kA
Poles Description3P
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage240 V AC
Complementary
- Mounting Mode
- plug-in
- Awg Gauge
- AWG 14...AWG 1/0 copper
Electrical Connectionscrew connector
Environment
- Product Certifications
- CSA
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Rohs Exemption InformationYes
Eu Rohs DirectiveCompliant with Exemptions
