Federal Pioneer NA3P15 Stab-Lok Circuit Breaker, 15A, 3 Pole, 240VAC, 10kA, Plug-In Mount
- MPN: NA3P15
- UPC: 047569370861
- PPN: SCH-NA3P15
CAD
$458.25
/ EA
Available to Order
Available to Ship Same/Next Business Day if In Stock and Ordered before 12:00 PM EST
Company Stock:
0
Loading dialog...
Looking to buy a large quantity?
To view product inventory
Description
Stab-Lok circuit breakers are one, two, and three pole thermal magnetic circuit breakers that provide arc fault circuit interrupters for Federal Pioneer panels. They have easy to read color coded handles to differentiate ampere ratings. This breaker is a three pole 15A, 240VAC moulded case breaker with plug in mounting. This circuit breaker meets CSA standards.
Documentation & Downloads
Specifications
Key Specifications
- Range Of Product
- Stab-lok
- [In] Rated Current
- 15 A
- Breaking Capacity
- 10 kA
Poles Description3P
Product Or Component Typeminiature circuit-breaker
[Ue] Rated Operational Voltage240 V AC
Complementary
- Mounting Mode
- plug-in
- Awg Gauge
- AWG 14...AWG 1/0 copper
Electrical Connectionscrew connector
Environment
- Product Certifications
- CSA
Offer Sustainability
- China Rohs Regulation
- Product out of China RoHS scope. Substance declaration for your information
- Mercury Free
- Yes
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
Rohs Exemption InformationYes
Eu Rohs DirectiveCompliant with Exemptions
