Telemecanique Sensors ABE7CPA01 Modicon ABE7 Connection Sub-Base, 2 Channels, 24V DC
- MPN: ABE7CPA01
- PPN: SCH-ABE7CPA01
CAD
$214.15
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Modicon ABE7 Connection Sub-Base from Schneider Electric is a robust solution designed for efficient automation and control within industrial applications. This sub-base features two channels and operates on a 24V DC power supply, ensuring reliable connectivity and integration with various I/O modules. As part of Schneider Electric's commitment to enhancing PLC, HMI, and data acquisition systems, this sub-base facilitates seamless communication and flexibility in your operations. Its engineered design ensures optimal performance in demanding environments, making it an essential component for modern automation systems.
Documentation & Downloads
Specifications
Key Specifications
- Range Of Product
- Modicon ABE7
- Connections - Terminals
- screw type terminals, 1 x 0.09...1 x 1.5 mm² AWG 28...AWG 16) flexible with cable end || screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 12) solid || screw type terminals, 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 14) flexible without cable end || screw type terminals, 2 x 0.09...2 x 0.75 mm² AWG 28...AWG 20) flexible with cable end || screw type terminals, 2 x 0.2...2 x 2.5 mm² AWG 24...AWG 14) solid
Product Or Component Typeconnection sub-base for counter and analogue channels
Number Of Channels2 || 8 || 1
Complementary
- [Uc] Control Circuit Voltage
- 24 V DC
- Net Weight
- 0.3 kg
- Tightening Torque
- 0.6 N.m flat Ø 3.5 mm
- Connection To Plc
- SUB-D 15
- Function Of Module
- counting and analogue TSX Micro || counting, axis control, position control Premium
Installation CategoryII IEC 60664-1
Fixing Modeby clips (35 mm symmetrical DIN rail) || by screws (solid plate with fixing kit)
Product CompatibilityTSX Micro TSX3722 || Premium TSXCAY21 || Premium TSXCAY41 || Premium TSXCTY2A || Premium TSXCTY4A || TSX Micro TSXCTZ1A || TSX Micro TSXCTZ2A
[Ui] Rated Insulation Voltage2000 V terminals/mounting rails
Environment
- Product Certifications
- DNV || CSA || UL || GL || EAC
- Ambient Air Temperature For Operation
- 0-60 °C
- Vibration Resistance
- 2 gn 10-150 Hz)IEC 60068-2-6
- Pollution Degree
- 2 IEC 60664-1
- Ambient Air Temperature For Storage
- -40-80 °C IEC 61131-2
- Resistance To Fast Transients
- 2 kV level 3 IEC 61000-4-4
Resistance To Radiated Fields10 V/m 26000000-1000000000 Hz)IEC 61000-4-3 level 3
Shock Resistance15 gn 11 ms IEC 60068-2-27
Ip Degree Of ProtectionIP20 IEC 60529
Resistance To Incandescent Wire750 °C IEC 60695-2-11
Resistance To Electrostatic Discharge4 kV contact) level 3 IEC 61000-4-2 || 8 kV air) level 3 IEC 61000-4-2
Contractual warranty
- Warranty
- 18 months
Offer Sustainability
- Rohs Exemption Information
- Yes
- Environmental Disclosure
- ENVPEP121229EN
- Reach Regulation
- Reference contains Substances of Very High Concern above the threshold
- China Rohs Regulation
- X
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Mercury FreeYes
Sustainable Offer StatusGreen Premium product
WeeeThe product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
Circularity ProfileENVEOLI1212029EN
