Schneider Electric ABE7R08S210 Electromechanical Relay Sub-Base, 8 Channels, 125 mm Width, 5 A
- MPN: ABE7R08S210
- PPN: SCH-ABE7R08S210
CAD
$253.85
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Loading dialog...
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Spec sheet
Description
This electromechanical relay sub-base from Schneider Electric is designed to enhance automation and control applications with its robust construction and reliable performance. Featuring eight channels and a compact width of 125 mm, it allows for efficient integration within your control systems, making it an essential component for those seeking to optimize their workflow. Its compatibility with various relay configurations makes it a versatile choice for both simple and complex projects, ensuring reliable connections while maintaining space efficiency.
Documentation & Downloads
Specifications
Key Specifications
| Country of Origin | China, France, Latvia |
|---|
Complementary Attributes
| Maximum Current Per Output Common | 10 A |
|---|---|
| Maximum Switching Voltage | 250 V AC 50/60 Hz IEC 60947-5-130 V DC IEC 60947-5-1 |
| Maximum Power Dissipation Per Channel In W | 0.36 W PLC end) |
|---|---|
| Minimum Switching Current | 10 mA >= 5 V |
Important Information Attributes
| Persona Type Ids | EU, OM, OM8 |
|---|---|
| Contact Bounce Time | <= 5 ms 1 NO, <= 5 ms 1 NO<= 5 ms 1 NO, <= 5 ms 1 NO |
| Operating Time | <= 10 ms coil energisation and NO closing, <= 10 ms coil energisation and NO closing, <= 5 ms coil de-energisation and NO opening, <= 5 ms coil de-energisation and NO opening<= 10 ms coil energisation and NO closing, <= 10 ms coil energisation and NO closing, <= 5 ms coil de-energisation and NO opening, <= 5 ms coil de-energisation and NO opening |
| Certificate Agency | UL, DNV, CSA, GL, EAC |
| Carbon Footprint Of The End-of-life Phase [C1 To C4] | 0.8 kg CO2 eq., 0.7555961150322937 |
| Carbon Footprint Of The Manufacturing Phase [A1 To A3] | 10 kg CO2 eq., 9.844205637405432 |
| Local Data Status | Publishable |
| Return Indicator | N |
| Stock Policy | 2 |
| Serviceability | No |
| Weee Scope | In |
| Scope Perimeter | At least in Europe |
| End Of Life Doc Ref | ENVEOLI1212029EN |
| Reach Full Compliance Status Id | CONTAINS_SVHC |
| Rohs Eur In Scope | No |
| Rohs Eur Conformity Date | 1845 |
| China Rohs In Scope | Yes |
| With Recycled Cardboard | Yes |
| Product Contributes To Saved And Avoided Emissions | No |
| Tier | 1 |
| Function Option | Standard |
| Market Segmentation | Industrial |
| Contacts Type And Composition | 1 NO preactuator end |
| Dielectric Strength | 2000 V IEC 60947-1 |
| Fixing Mode | by clips (35 mm symmetrical DIN rail)by screws (solid plate with fixing kit) |
| Max Immunity To Microbreaks | 5 ms |
| Number Of Channels | 8 |
| Operating Rate In Hz | 10 Hz no load0.5 Hz at Ie |
| Product Availability | Non-Stock - Not normally stocked in distribution facility |
| Protective Treatment | TC |
| Resistance To Fast Transients | 2 kV level 3 IEC 61000-4-4 |
| Resistance To Radiated Fields | 10 V/m 26000000-1000000000 Hz)IEC 61000-4-3 level 3 |
| Shock Resistance | 15 gn 11 ms IEC 60068-2-27 |
| Sustainable Packaging | No |
| Threshold Tripping Voltage | 19.7 V 40 °C |
| Total Lifecycle Carbon Footprint | 982 kg CO2 eq. |
| Pep Code | ENVPEP1212029_V4 |
| Pep Verification Date | 2026-06-18 |
| Psr Version | No PSR |
| Data Source | extrapolated product |
| Functional-unit Quantity | 1 |
| Reference Lifetime In Y | 10 |
| Energy Model - Manufacturing [A1-a3] | Electricity Mix; Low voltage; 2020; Latvia, LV |
| Energy Model - Use [B6] | Electricity Mix; Low voltage; 2020; Europe, EU-27 |
| Recyclability Potential In % | 6 |
| [Ui] Rated Insulation Voltage | 2000 V |
| [Us] Rated Supply Voltage | 24 V DC PLC end |
| Drop-out Voltage | 2.4 V 20 °C PLC end) |
| Package Weight(Lbs) | 351.000 g |
| Warranty (In Months) | 18 |
| Persona Type Names | End User, Original Equipment Manufacturer, OEM - Control Panelbuilder |
|---|---|
| Electrical Durability | 500000 cycles 600 mA 24 V DC-13 10 ms preactuator end), 500000 cycles 1500 mA 230 V AC-12 preactuator end), 500000 cycles 1500 mA 24 V DC-12 preactuator end)500000 cycles 900 mA 230 V AC-15 preactuator end) |
| Switching Frequency | <= 0.5 Hz, <= 10 Hz, <= 0.5 Hz, <= 10 Hz |
| Carbon Footprint Of The Distribution Phase [A4] | 0.052405091690763156, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Installation Phase [A5] | 0.09293763248213918, 0.1 kg CO2 eq. |
| Carbon Footprint Of The Use Phase [B2 B3 B4 B6] | 972 kg CO2 eq., 971.7360356355297 |
| Local Publishable Date | 2026-01-12 |
| Stocking Flag | Y |
| Device Type | PLC System - PLC Component |
| Traceability | No |
| Weee Product Category | 5 |
| Eoli Availability Display | Yes |
| Reach Full Compliance Status | Reference contains Substances of Very High Concern above the threshold |
| Reach Compliance Directive | Reference contains Substances of Very High Concern above the threshold |
| Rohs Eur Status | Compliant By Exemption |
| Rohs Eur Full Compliance Status | Compliant By Exemption |
| China Rohs Label | 5 |
| Without Single Use Plastic | Yes |
| Tier Id | 1 |
| Function Option Id | STANDARD |
| Market Segmentation Id | INDUSTRIAL |
| Product Kit Identifier | N |
| Current Per Channel | 5 A preactuator end |
| Electrical Reliability | 1e-008 |
| Installation Category | II IEC 60664-1 |
| Mechanical Durability | 20000000 cycles |
| Number Of Terminal Per Channel | 2 |
| Polarity Distribution | volt-free |
| Product Or Component Type | electromechanical output relay sub-base |
| Range Of Product | Modicon ABE7 |
| Resistance To Incandescent Wire | 750 °C 30 s IEC 60695-2-11 |
| Returnability | No |
| Software Version | v6.2.5-6 |
| Terminal Block Type | removable |
| Tightening Torque | 0.6 N.m flat Ø 3.5 mm |
| Weee Label | The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins. |
| Database Version | 2024-01 |
| Pcr Version | PCR-4-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Functional-unit Description | To connect I/O to channels of operative parts for 10 years, 100% of the time in industrial atmosphere. |
| Functional-unit Unit | unit |
| Energy Consumption On Product Lifetime In Kwh | 2102.4 |
| Energy Model - Installation [A5] | No energy used |
| Energy Model - End Of Life [C1-c4] | Global, European and French datasets are used. |
| Width Nominal | 125 mm |
| [Uimp] Rated Impulse Withstand Voltage | 2.5 kV IEC 60947-1 |
| Drop-out Current | 1 mA 20 °C |
| Nbr. Of Units In Pkg. | 1 |
| Take-back | No |
| Customs Code | 8536904000 |
Environment Attributes Main
| Ambient Air Temperature For Operation | -5-60 °C IEC 61131-2, -5-60 °C IEC 61131-2-5-60 °C IEC 61131-2, -5-60 °C IEC 61131-2 |
|---|---|
| Take Back | No |
| China Rohs Regulation | X |
| Carbon Footprint | 982.4811801121404 |
| Environmental Disclosure | ENVPEP1212029_V4 |
| Ip Degree Of Protection | IP2X conforming to IEC 60529 |
| Packaging Without Single Use Plastic | Yes |
| Pep Code | ENVPEP1212029_V4 |
| Pcr Version | PCR-4-ed4-2021 09 06 |
| Type Of Verification For The Pep | Independent internal review |
| Ambient Air Temperature For Storage | -40-80 °C IEC 61131-2, -40-80 °C IEC 61131-2-40-80 °C IEC 61131-2, -40-80 °C IEC 61131-2 |
|---|---|
| Recycled Metal Content At Cr Level | 0 % |
| Mercury Free | Yes |
| Circularity Profile | ENVEOLI1212029EN |
| Eu Rohs Directive | Compliant By Exemption |
| Packaging Made With Recycled Cardboard | Yes |
| Reach Regulation | Reference contains Substances of Very High Concern above the threshold |
| Pep Verification Date | 2026-06-18 |
| Psr Version | No PSR |
General Attributes
| Product Or Component Type | electromechanical output relay sub-base |
|---|
| Range Of Product | Modicon ABE7 |
|---|
ETIM
| ETIM 8 | EC001284 |
|---|
| ETIM 9 | EC001284 |
|---|
Output Attributes
| Maximum Current Per Output Common | 10 A |
|---|
Contractual Warranty Attributes
| Warranty Period | 18 months |
|---|
| Warranty | 18 months |
|---|
