Schneider Electric T02CN13U7 TeSys N Non-Reversing Contactor, 3 Pole, 27A, 10HP, NEMA Size 1

MPN: T02CN13U7
PPN: SCH-T02CN13U7
UNSPSC: 39121529

$755.18

Available to Order

Lead times may vary. For an accurate estimate please contact us.

Available To Ship Immediately:0

Loading dialog...

Loading add to cart quantity...

Looking to buy a large quantity?

To View Branch Inventory And Your Custom Pricing

Spec sheet

Compare

Description

TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. This 3 pole NEMA size 1 nonreversing contactor mounts on 35mm DIN rail and has a 27 amperage continuous current rating. This contactor has 2 HP at 115 VAC and 3 HP at 230 VAC single phase ratings. The contactor also has ratings of 7.5 HP at 200 to 230 VAC and 10 HP at 460 and 575 VAC poly phase. The nonreversing contactor is wired for common control with a 240 VAC 50/60 Hz replaceable coil. Contactor has 1 normally open and 1 normally closed auxiliary contact. This contactor is not in an enclosure. This contactor is 3.34 inches tall, 1.76 inches wide and 3.66 inches deep. It weighs 0.93 lbs. The screw clamp terminals will accept power wires from 14 AWG to 6 AWG and control wires from 18 AWG to 10 AWG. This TeSys N contactor is UL listed and CSA Certified.

Features

High density, space saving design
Sizes 00 -2 are DIN rail and panel mountable
Replacing coils requires no tools
Common accessories across range
UL Listed, CSA certified, and CE marked
Replaceable contacts on Size 3 and larger contactors reduce overall costs
Snap-on front and side mount accessories for easy installation

Documentation & Downloads

Specifications

Key Specifications

Country of Origin	France, United States

Depth	3.66 in

Complementary Attributes

Maximum Horse Power Rating	7.5 hp 200 V AC, 7.5 hp 230 V AC10 hp 460 V AC, 10 hp 575 V AC
Line Rated Current	27 A
Ue Rated Operational Voltage	600 V AC

Control Circuit	common control circuit
Uc Control Circuit Voltage	240 V AC

Important Information Attributes

Persona Type Ids	EU, LC, OM, OM8, PB, SC
Market Segmentation Id	COMMERCIAL, INDUSTRIAL
Certificate Agency	UL Listed, CSA
Local Publishable Date	2026-08-18
Device Type	LV equipment - LV contactor
Traceability	No
Average Life Duration	20 year(s)
Weee Product Category	5
Eoli Availability Display	Yes
Rohs Eur In Scope	Yes
Rohs Eur Conformity Date	1904
China Rohs In Scope	No
With Recycled Cardboard	Yes
Product Contributes To Saved And Avoided Emissions	No
Tier	2
Function Option	Standard
Contactor Application	non-reversing
Energy Efficiency Optimized	False
Phase	3 phase
Product Or Component Type	contactor
Returnability	Yes
Height Nominal	3.34 in
Nbr. Of Units In Pkg.	1
Warranty In Months	18

Persona Type Names	End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder, Electrician
Market Segmentation	Commercial, Industrial
Local Data Status	Publishable
Return Indicator	Y
Serviceability	No
Field Service Division	PPIBS
Weee Scope	In
Scope Perimeter	Outside of Europe
End Of Life Doc Ref	ENVEOLI110229EN
Rohs Eur Status	Compliant
Rohs Eur Full Compliance Status	Compliant
China Rohs Label	1
Without Single Use Plastic	Yes
Tier Id	2
Function Option Id	STANDARD
Product Kit Identifier	N
Electrical Connection	screw clamp terminals
Number Of Poles	3P
Product Availability	Stock - Normally stocked in distribution facility
Range Of Product	TeSys N
Sustainable Packaging	Yes
Width Nominal	1.76 in
Customs Code	8536490065

Environment Attributes Main

China Rohs Regulation	Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
Reach Free Shvc	Yes
Toxic Heavy Metal Free	Yes
Circularity Profile	ENVEOLI110229EN
Eu Rohs Directive	Compliant
Nema Size	1
Packaging Without Single Use Plastic	Yes
Pep Code	ENVPEP110229EN

Take Back	No
Recycled Metal Content At Cr Level	0 %
Mercury Free	Yes
Environmental Disclosure	ENVPEP110229EN
Nema Degree Of Protection	not rated (open device)
Packaging Made With Recycled Cardboard	Yes
Reach Free Of Svhc	Yes
