Schneider Electric XACB020 Empty pendant control station, Harmony XAC, plastic, yellow, 2 cut outs, for cable 7...13mm
Schneider Electric XACB020 Empty pendant control station, Harmony XAC, plastic, yellow, 2 cut outs, for cable 7...13mm
- MPN: XACB020
- PPN: SCH-XACB020
Spec sheet
Loading compare button...
Available to Order
Company Stock:
0
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To view product inventory
CAD$231.66/ EA
Description
This yellow empty pendant station for control or power circuits is designed for small hoist applications. Its design makes it simple and intuitive, but also very comfortable for the operator to use. It comprises a glass reinforced polyester enclosure with 2 vertical openings diameter 22mm and operator cut-out centres 40 mm. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP65. This robust pendant control station complies with the safety requirements of IEC standards.
Specifications
Complementary
- Product Certifications
- CSA type 4
- Guard Rail
- without
- Standards
- CSA C22.2 No 14 || IEC 60947-5-1
- Shock Resistance
- 100 gn IEC 60068-2-27
- Vibration Resistance
- 15 gn 10-500 Hz)IEC 60068-2-6
- Ip Degree Of Protection
- IP65 IEC 60529
- Control Station Type
- double insulated
- Ambient Air Temperature For Storage
- -40-70 °C
- Control Station Colour
- yellow
- Electrical Circuit Type
- power circuit || control circuit
- Protective Treatment
- TH
Ik Degree Of ProtectionIK08 conforming to IEC 62262
Ambient Air Temperature For Operation-25-70 °C
Cable Entryrubber sleeve with stepped entry 7-13 mm
Enclosure Typeempty enclosure
Net Weight0.76 kg
Vertical Operator Cut-Out Centre40 mm
Number Of Cut-Out2 cut-outs
Overvoltage Categoryclass II IEC 61140
Mechanical Durability1000000 cycles
Enclosure Materialglass reinforced polyester
Specifications
- Range Of Product
- Harmony XAC
- Device Short Name
- XACB
Product Or Component Typependant control station
Offer Sustainability
- Rohs Exemption Information
- Yes
- Toxic Heavy Metal Free
- Yes
- Reach Free Of Svhc
- Yes
- Eu Rohs Directive
- Pro-active compliance (Product out of EU RoHS legal scope)
Mercury FreeYes
Reach RegulationFree of Substances of Very High Concern above the threshold
China Rohs RegulationX
Contractual warranty
- Warranty
- 18 months
