Schneider Electric

Schneider Electric XVC4B25S Harmony XVC, Monolithic precabled tower light, plastic, red orange, Ø40, tube mounting, steady or flashing, buzzer, IP23, 24 V AC/DC

Harmony XVC, Monolithic precabled tower light, plastic, red orange, Ø40, tube mounting, steady or flashing, buzzer, IP23, 24 V AC/DC
  • MPN: XVC4B25S
  • PPN: SCH-XVC4B25S

Spec sheet

Loading compare button...

  • If you can't find the product or are unsure which one you need, please use the Product Selector tool below
    • Available to Order

    Company Stock:

    0

    Lead times may vary. For an accurate estimate please contact us.

    Loading dialog...

    Looking to buy a large quantity?

    To view product inventory

    CAD$332.34/ EA

    Description

    Harmony XVC, Monolithic precabled tower light, plastic, red orange, Ø40, tube mounting, steady or flashing, buzzer, IP23, 24 V AC/DC

    Specifications

    Environment

    Product Certifications
    UL
    Ambient Air Temperature For Storage
    -35-70 °C
    Standards
    EN/IEC 61000-6-2 || EN/IEC 61000-6-3
    Protective Treatment
    TC
    Ambient Air Temperature For Operation-10-50 °C
    Overvoltage Categoryclass I EN/IEC 61140
    Electrical Shock Protection Classclass I EN/IEC 61140
    Ip Degree Of ProtectionIP23 vertical surface installation EN/IEC 60529

    Contractual warranty

    Warranty
    18 months

    Offer Sustainability

    China Rohs Regulation
    X
    Rohs Exemption Information
    Yes
    Environmental Disclosure
    ENVPEP1904008EN
    Circularity ProfileENVEOLI1904008EN
    Mercury FreeYes
    Eu Rohs DirectivePro-active compliance (Product out of EU RoHS legal scope)

    Complementary

    [Us] Rated Supply Voltage
    24 V
    Awg Gauge
    AWG 22
    Fundamental Frequency
    2.23 kHz
    Cable Cross Section
    0.33-0.33 mm²
    Material
    polycarbonate: illuminated unit || ABS (acrylonitrile butadiene-styrene): base unit || PBT + ABS (UL94HB): top cover || SGP (chromium-plated): support tube
    Marking
    CE
    Mounting Location
    on support tube, 17 mm
    Height559.5 mm
    [Uimp] Rated Impulse Withstand Voltage0.8 kV
    Flashing Frequency1 Hz
    Product Mountingon support tube, 17 mm
    Cable Length900 mm
    Net Weight0.62 kg
    Current Consumption90 mA

    Specifications

    Range Of Product
    Harmony XVC4
    Beacon Or Indicator Bank Unit Type
    2 illuminated units
    Supply Circuit Type
    AC/DC
    Product Or Component Type
    complete pre-wired monolithic tower light
    Sound Signalling
    buzzer
    Noise Level70-85 dB continuous or intermittent tone)1 m
    Mounting Diameter40 mm
    Light SourceLED steady or flashing red || LED steady or flashing orange
    Component NameXVC
    Device Short NameXVC
