Square D 9001SK72J1R Harmony Selector Switch, 30mm, Red, 3 Positions, 110-120V
- MPN: 9001SK72J1R
- UPC: 785901932925
- PPN: SCH-9001SK72J1R
CAD
$252.63
/ EA
Available to Order
Lead times may vary. For an accurate estimate please contact us.
Looking to buy a large quantity?
To View Branch Inventory And Your Custom Pricing
Description
The Schneider Electric Harmony Selector Switch is a robust and versatile device designed for automation and control applications. This 30mm red selector switch features three distinct positions, allowing for easy operation and selection in complex systems. Operating at 110-120V, it combines functionality with a striking design, making it a reliable choice for professionals seeking efficiency and clarity in their control panels. With its durable construction, this illuminated switch is not only functional but also enhances the visibility of control functions in various industrial settings.
Documentation & Downloads
Specifications
Additional
- Voltage
- 110...120 V AC 50/60 Hz
- Mechanical Durability
- 500000 cycles
- Electrical Shock Protection Class
- Class II IEC 61140
- Shock Resistance
- 50 gn IEC 60068-2-27
- Mounting Diameter
- 30 mm
- Operator Profile
- Standard handle
- Light Source
- Incandescent bulb
- Bezel Material
- Plastic
- Ambient Air Temperature for Operation
- -25 to 70 0B0C
- NEMA Degree of Protection
- NEMA 1, NEMA 2, NEMA 3, NEMA 3R, NEMA 4, NEMA 4X, NEMA 6, NEMA 12, NEMA 13
- Product Certifications
- NEMA, UL 508
- Color
- Red
Positions3 positions
IP Degree of ProtectionIP66 IEC 60529
Vibration Resistance7 gn 2-500 Hz IEC 60068-2-6
Size30 mm
Type of OperatorRight to centre spring return
Cam Profile2
Bulb BaseBA 9s
Protective TreatmentTC
Ambient Air Temperature for Storage-40 to 70 0B0C
StandardsUL 508, JIS C 852, EN/IEC 60947-5-4, EN/IEC 60947-5-1, EN/IEC 60947-1, JIS C 4520, CSA C22.2 No 14
ComplianceRoHS, REACh, China RoHS, Reach Free Of Svhc
Country of OriginMX
